Прямые продажи от производителя износостойкое графитовое упаковочное кольцо
- Category: Other Graphite Products >>>
- Supplier: Langfang,Xinlai,Fireproof,Material,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Aramid packing ring is made of aramid fiber impregnated with PTFE emulsion and treated with lubricant. Good chemical resistance,high rebound, low cold flow. With excellent high speed, high modulus properties (called artificial wire) it is three times stronger and five times lighter than wire. Therefore, compared with other types of packing, it can resist granular crystallization medium and higher temperature can be used alone or in combination with other packing. It is a good substitute for asbestos in the pump system.
Product name | Aramid packing ring |
PH | 2-12 |
Temperature | -100-280℃ |
Density | 1.4 |
Features | Excellent lubricity and wear resistance |
Product specifications | 3X3mm--60X60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
The carbon packing ring is mainly made of carbon fiber, which has the characteristics of high temperature resistance (＞ 3000 ° C) , ablation resistance, small Coefficient of thermal expansion, high specific strength and high specific die, widely used in aerospace, aviation, chemical, electronic and sports equipment and other fields. With good heat conductivity, wear resistance, chemical stability, and high mechanical strength, starting torque is small, used in petroleum, chemical industry, chemical fiber, coal mining, power generation, metallurgy and other industrial fields of flange, valve, reactor, pump sealing.
Product name | Carbon Packing Ring |
PH | 1-14 |
Temperature | -200-350℃ |
Density | 1.4 |
Features | Excellent thermal conductivity, wear resistance, chemical stability |
Product specifications | 3X3mm--60x60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
Aramid carbon mixed packing suitable for water, sea water, steam, all kinds of oil, solvent, weak acid, alkali, ethanol and other grinding media, used in chemical fiber, fertilizer, oil extraction, ethylene, pharmaceutical, sugar, paper, power and other industrial fields of high-pressure pumps, valves, reactor sealing. Aramid carbon braided packing has the characteristics of good thermal conductivity and small friction coefficient, especially suitable for high-speed parts of the seal.
Product name | Aramid carbon packing ring |
PH | 2-13 |
Temperature | -100-300℃ |
Density | 1.4 |
Features | The aramid carbon packing ring is made of aramid thread and carbon fiber thread woven into packing. |
Product specifications | 3X3mm--60x60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
Aramid polytetrafluoroethylene blending packing has the characteristics of aramid abrasion resistance and polytetrafluoroethylene acid and alkali corrosion resistance. It can be used for sealing flanges, valves, reactors and pumps in chemical industry, food industry, etc. . It can also be used for all chemical media except soluble alkali metal.
Product name | Aramid Teflon packing ring |
PH | 2-13 |
Temperature | -100-300℃ |
Density | 1.4 |
Features | Wear resistance, high temperature resistance |
Product specifications | 3X3mm--60X60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
PTFE is woven from pure polytetrafluoroethylene fibers and is not treated with PTFE emulsion or grease. Because it is made of solid braid and flexible and adjustable, so with the shaft, packing box can be very good with excellent corrosion resistance, good self-lubrication and anti-adhesion. Can be used in chemical industry, food, medicine, paper, chemical fiber fine chemical industry, such as does not allow the operation of pollution.
Product name | PTFE packing ring |
PH | 0-14 |
Temperature | -100-260℃ |
Density | 1.4 |
Features | Suitable for melting alkali metals and free fluorine ions other than all media |
Product specifications | 3X3mm--60x60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
Graphite packing ring is made of various kinds of reinforced fiber, metal wire (steel wire, copper wire, nickel wire, carbon fiber, pre-oxygen wire glass yarn) and other reinforced graphite wire. Suitable for dynamic sealing under high temperature and high pressure. It can be used for sealing hot water, superheated steam, heat transfer fluids, ammonia solutions, hydrocarbons,cryogenic liquids, etc. , mainly used in high temperature, high pressure, corrosion-resistant media under the valve, pump, reactor seal. It is also a unique universal sealing packing.
Product name | Graphite packing ring |
PH | 0-12 |
Temperature | -100-800℃ |
Density | 1.4 |
Features | Corrosion resistance, suitable for high temperature, high pressure valves and other static sealing parts. |
Product specifications | 3X3mm--60X60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
The graphite packing ring is made by pressing the graphite belt, without any fillers and binders, and its purity is more than 98%. The standard cross section of the packing ring is square. It can also be machined into wedge or V shape. It is suitable for highpressure.
Graphite packing ring suitable for acid, alkali and solvent and other strong corrosive media and non-polluting media; also used for high-pressure valves, piston pumps, agitators, etc. . Media can not be contaminated places such as food, medicine, paper,chemical fiber and other industries.
Product name | Graphite packing ring |
PH | 0-14 |
Temperature | 800℃ |
Density | 1.0-1.7 |
Features | Good compression resilience and high strength |
Product specifications | 3X3mm--60x60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
High water-based packing ring outstanding advantages are very low coefficient of friction, no wear shaft, anti-corrosion. High water-based packing ring equipment: low-pressure valves, rotary equipment, and reciprocating pump hydraulic press, ship propeller.High water-based packing ring industry: shipbuilding industry, cold water treatment, sea water treatment. High water base packing ring suitable medium: suitable for all kinds of water quality, sea water, salt water, oil, lipids, weak acid, weak alkali, etc.
Product name | High water base packing ring |
PH | 4-11 |
Temperature | -20-210℃ |
Density | 1.4 |
Features | Suitable for melting alkali metals and free fluorine ions other than all media. |
Product specifications | 3X3mm--60x60mm Special specifications or all kinds of non-standard products can be customized according to customer requirements |
Product Pictures
Company Profile
Certifications
Packing & Delivery
1. Delivery Date?
Usually 10-15 days after receipt of deposit, the specific delivery date depends on the order quantity.
2. How will you conduct quality control?
We will supervise all processes before and after production until we ship the goods from the factory.
3. What's Your Minimum Order?
3. What's Your Minimum Order?
The minimum order may vary according to customers' special requirements; we try our best to meet your business needs.
4. What kind of products do you offer?
4. What kind of products do you offer?
The company can provide a variety of fire sealing materials. For example: metal winding gasket, non-asbestos gasket, industrial rubber plate, Teflon Plate, teflon gasket, ceramic fiber cloth, fireproof cloth, glass fiber cloth, rubber gasket, non-asbestos gasket, Teflon rod, graphite paper, graphite gasket, graphite packing, Teflon packing, aramid packing, carbon fiber packing and other products.
5. Can we have a look around your factory?
5. Can we have a look around your factory?
Yes! Of course, you are welcome to visit our factory anytime on site or online!
