DN15 6000 Portable Flow Sensor Meter Ultrasonic Water Flow Sensor Oil Flow Meter
- Category: >>>
- Supplier: Dalian Zhuochuan Technology Co. Ltd.
Share on (1600713560613):
Product Overview
Description
Category | Performance and parameters | ||
Host | Principle | Principle of ultrasonic time difference | |
Accuracy | ±1% | ||
Display | 4x8 Chinese or 4x16 Western dot matrix LCD with support of Chinese / English / Italian / French | ||
Signal output | 1 channel OCT pulse output (pulse width 6 ~ 1000ms, default 200ms) | ||
Data interface | The RS232 serial interface is isolated and the flowmeter can be upgraded by PC computer | ||
The Conduit situation | Pipe | Steel / stainless steel / cast iron / steel / PVC. Aluminum / glass fiber reinforced plastic and other dense pipes are allowed to be lined | |
Tube inner diameter | 15-6000MM | ||
Straight pipe section | The sensor installation point is best to meet: upstream 10D, downstream 5D, 30D from the outlet (D is the pipe diameter) | ||
Measuring medium | Type | Water / sea water / industrial sewage / acid-base liquid} alcohol / beer / oil and other single and uniform liquids that can conduct ultrasonic wave | |
Temperature | Temperature: - 30-160 ℃ | ||
Turbidity | 10000ppm and small bubble content | ||
Current Speed | 0±10M/S | ||
Working environment | Temperature | Main engine: - 20-60 ℃; flow sensor: - 30 ~ 160 ℃ | |
Humidity | Host: 85%RH; sensor grade: IP67 | ||
Power Supply | Three built-in 1.2V rechargeable NI-MH batteries with a capacity of 2000MAH, which can work continuously for more than 12 hours each time. AC90-260V power adapter can be used to achieve continuous measurement | ||
Power waste | 1w | ||
Shell material | Flame retardant ABS | ||
Main engine weight | 390G | ||
