Codi Energy 12V Lithium Ionen Ion 60V 48V 24V 180Ah 100ah 200ah Lifepo4 12 V lithium Phosphate Battery Lifepo4 Pack Battery
- Category: >>>
- Supplier: Codi Energy Ltd.
Share on (1600713666366):
Product Overview
Description
Products Description
●12V lithium battery module
●Max up to 4000 cycle times
●With the overcharge and overdischarge protection function
●With the overcurrent and shortcircuit protection function
●With the overtemperature protection function
●Application for off-grid solar power system
●Excellent standby self-consumption
●Intelligent BMS equipped inside to maintain the battery always work at best condition
●5-10 years life time , LiFePO4 battery, more stable and safe
●With the overcharge and overdischarge protection function
●With the overcurrent and shortcircuit protection function
●With the overtemperature protection function
●Application for off-grid solar power system
●Excellent standby self-consumption
●Intelligent BMS equipped inside to maintain the battery always work at best condition
●5-10 years life time , LiFePO4 battery, more stable and safe
Battery Specifications | ||||||||||
MODEL | 12V 100AH | 12V 120AH | 12V 200AH | 24V 100AH | 24V 200AH | |||||
Nomi n a l Pa ra mete rs | ||||||||||
Nominal voltage | 12V | 24V | ||||||||
Capacity | 100AH | 120AH | 200AH | 100AH | 200AH | |||||
Energy | 1200WH | 1440WH | 2400WH | 2400WH | 4800WH | |||||
Dimensions | 256*165*210mm | 328*171*215mm | 490*171*240mm | 490*171*240mm | 521*238*218mm | |||||
Weight | 12KG | 14.4KG | 19KG | 19KG | 32KG | |||||
Basic Pa ra mete rs | ||||||||||
Life cycles | 4000 Cycles | |||||||||
Operation Temperature | (-20°C~60°C ) | |||||||||
Communication | RS232,RS485,CAN | |||||||||
Certifications | CE, Rohs, FCC, UN38.3, MSDS | |||||||||
Management system | Built in BMS | |||||||||
Warranty BAT | 10 Years | |||||||||
Elect rica l | Pa ra mete rs | |||||||||
Max charging voltage | 12.8V | 14.6V | 29.2V | |||||||
Maximum Charging Current | 100A | 120A | 200A | 100A | 200A | |||||
Maximum Discharging Current | 100A | 120A | 200A | 100A | 200A | |||||
Max Power | 1200WH | 1440WH | 2400WH | 2400WH | 4800WH | |||||
More Capacity
VOLTAGE | CAPACITY | CHARGE | DISCHARGE | SIZE(MM) | WEIGHT (KG) | |
12V | 12AH | 0.2C-1C | 0.2C-2C | L151*W99*H84 | 1.5 | |
12V | 50AH | 0.2C-1C | 0.2C-2C | L223*W120*H175 | 6 | |
12V | 100AH | 0.2C-1C | 0.2C-2C | L256*W165*H210 | 12 | |
12V | 150AH | 0.2C-1C | 0.2C-2C | L406*W173*H236 | 17.5 | |
12V | 200AH | 0.2C-1C | 0.2C-1C | L490*W171*H240 | 19 | |
12V | 300AH | 0.2C-1C | 0.2C-1C | L521*W238*H218 | 23 | |
12V | 400AH | 0.2C-1C | 0.2C-1C | L521*W238*H218 | 32 | |
24V | 30AH | 0.2C-1C | 0.2C-2C | L521*W238*H219 | 12 | |
24V | 50AH | 0.2C-1C | 0.2C-2C | L256*W165*H210 | 12 | |
24V | 100AH | 0.2C-1C | 0.2C-2C | L490*W171*H240 | 19 | |
24V | 150AH | 0.2C-1C | 0.2C-2C | L521*W238*H218 | 23 | |
24V | 200AH | 0.2C-1C | 0.2C-1C | L521*W238*H218 | 32 | |
24V | 250AH | 0.2C-1C | 0.2C-1C | L460*W300*H200 | 36 | |
24V | 300AH | 0.2C-1C | 0.2C-1C | L460*W300*H240 | 48 | |
48V | 50AH | 0.2C-1C | 0.2C-2C | L490*W171*H240 | 19 | |
48V | 75AH | 0.2C-1C | 0.2C-2C | L460*W360*H160 | 35 | |
48V | 100AH | 0.2C-1C | 0.2C-2C | L450*W350*H150 | 32 | |
48V | 200AH | 0.2C-1C | 0.2C-1C | L500*W360*H230 | 65 | |
48V | 250AH | 0.2C-1C | 0.2C-1C | CUSTOM SIZE | ||
48V | 300AH | 0.2C-1C | 0.2C-1C | CUSTOM SIZE | ||
Our Factory
Project Cases
Payment and Delivery
T/T | EXW | 30% T/T in advance, paid the balance before shipment | |||
FOB | |||||
CNF | 30% T/T in advance, paid the balance against copy of B/L | ||||
CIF | |||||
L/C | L/C amount above 50,000 usd, we can accept L/C at sight | ||||
West Union | Amount lower than 5000usd | ||||
Delivery Time | 7~10days after receiving payment for one container | ||||
We welcome use Trade Assurance, you'll enjoy:
100% product quality protection
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
Certifications
FAQ
Q：How does your company carry out quality control?
Our QC team will do strict quality control inspection from the incoming materials and all way through the production processes to the completed products including the packaging before we ship them out.
Q：Can you do OEM & ODM?
Yes, we do OEM & ODM orders. An Non-disclosure agreement would be signed before the clients proceed to send us their designs. Our engineering team will provide feasible suggestions and ensure clients will get the best
Our QC team will do strict quality control inspection from the incoming materials and all way through the production processes to the completed products including the packaging before we ship them out.
Q：Can you do OEM & ODM?
Yes, we do OEM & ODM orders. An Non-disclosure agreement would be signed before the clients proceed to send us their designs. Our engineering team will provide feasible suggestions and ensure clients will get the best
Q：Can i get a sample from you for quality checking?
Yes, for those ready to ship items, samples are available and can be shipped to clients. For custom design products, we would need time to produce.
Q：What about the lead time for mass products?
It mainly depends on the quantity and requirements. It could be from 1 day to 30 days.
Q：Are you a trader or factory?
we are the professional manufacturers with more than 100 employees.
Q：Can I visit your factory?/Where is your factory located?
Yes. Welcome to contact us if you would like to visit
Yes, for those ready to ship items, samples are available and can be shipped to clients. For custom design products, we would need time to produce.
Q：What about the lead time for mass products?
It mainly depends on the quantity and requirements. It could be from 1 day to 30 days.
Q：Are you a trader or factory?
we are the professional manufacturers with more than 100 employees.
Q：Can I visit your factory?/Where is your factory located?
Yes. Welcome to contact us if you would like to visit
Q：Where is your main market?
Now the biggest market we have are: USA, Australia, and Europe etc.
Q：What certification do you have?
CE/RoHs/FCC/UL and many Patent certificates;
Q：What's your warranty period?
We provide 1 to 10 year warranty for different products.
Now the biggest market we have are: USA, Australia, and Europe etc.
Q：What certification do you have?
CE/RoHs/FCC/UL and many Patent certificates;
Q：What's your warranty period?
We provide 1 to 10 year warranty for different products.
