BK Broadcom Bluetooth 4.0 mesh

Bluetooth remote control (open distance 100 meters-between 200 meters) . (low packet loss rate) application area: Bluetooth, this link for the scheme connection. BK Broadcom Bluetooth 4.0MESH (3431Q chip) specification area of application: Bluetooth remote control (open distance 100-200 meters) . (low packet loss rate) generalization, a main network module-→ main (transmit)-→ from (receive)



Distribution network flow: 4 commands to complete: 1. Configure device Key2.0. Configure network Key3.0. Configure app Key4.0. Add the above three key configuration devices key command format CMD (2byte) + Dev (16byte) where CMD is fixed 0x6001 for example setting device key to 95bC81C0C9C99921DBBF63F90E1CE7F4, command 600195BC81C0C9C9921DBBF63F90E1CE7F4 configure the network key command format CMD (2byte) + network (2byte) + Dev (16byte) where CMD is fixed 0x6002 and index is large. For example, set device key index 0x0001 to Network Dey 1122345567889AABBCCDDEEFF0F, command 6002000112234556788899AABBCCDDEEFF0F configure app key command format CMD (2byte) + appkey (2byte) + app (16byte) where CMD is fixed 0x6002 and appkey index is large. For example, set device appkeyindex to 0x0001 and Appkeydey to a801711330200001bd7bc07a7800000, the commands are as follows: 60030001a801711330200001bd7bc07a780000000 add the above three key -LRB-important) command formaCMD cmd (2byCMD cmd is registered with the 6004 receive node
