Abrasion Resistant Ceramic Rubber Plate Ceramic Liner
- Category: >>>
- Supplier: Hanpeng Material Rubber Industry (liaoning) Co. Ltd.
Share on (1600716546217):
Product Overview
Description
Product Description
Features of ceramic wear pads:
1.Rubber ceramic coating combine energy absorbing rubber with excellent abrasion resistant high alumina ceramic
2.Impact resistance,Anti-corrosion,Noise reduction,Unsurpassed Resistance,Longest Wear Life Available.
3.custom sizes available at customers request,custom shapes and sizes rubber ceramic coating to meet your specific
requirements,standard liners and non-standard ones are all available.
4.Manufacturer with rich experience,good bond between rubber and ceramic,ceramics stay in place until completely worn.
5.wide range of rubber ceramic coating to meet your different requirements
1.Rubber ceramic coating combine energy absorbing rubber with excellent abrasion resistant high alumina ceramic
2.Impact resistance,Anti-corrosion,Noise reduction,Unsurpassed Resistance,Longest Wear Life Available.
3.custom sizes available at customers request,custom shapes and sizes rubber ceramic coating to meet your specific
requirements,standard liners and non-standard ones are all available.
4.Manufacturer with rich experience,good bond between rubber and ceramic,ceramics stay in place until completely worn.
5.wide range of rubber ceramic coating to meet your different requirements
applications
* CERA-WEAR Ceramic Wear Pads have been designed primarily for use as a ceramic lining for the wear and corrosion protection of steel surfaces.
* It’s mainly used for high-speed wet abrasion applications such as slurry handling in the mineral processing industry but can be used for any fine particle abrasion applications.
CERAMIC SPECIFICATIONS
Aluminum Oxide Al2O3:92 % (min)
Density (g/cc):3.65 (min)
Hardness (R45N):77 (min)
Flexural Strength (Mpa):240 (min)
Abrasion By Rubbing (g):0.1 (max)
RUBBER SPECIFICATIONS
Hardness (Shore ‘A’):65+/-5
Density (g/cc):1.12 to 1.17
Tensile Strength (Mpa):20.0 (min)
Elongation (min):400% (min)
Abrasion (mm3):120 (max)
* CERA-WEAR Ceramic Wear Pads have been designed primarily for use as a ceramic lining for the wear and corrosion protection of steel surfaces.
* It’s mainly used for high-speed wet abrasion applications such as slurry handling in the mineral processing industry but can be used for any fine particle abrasion applications.
CERAMIC SPECIFICATIONS
Aluminum Oxide Al2O3:92 % (min)
Density (g/cc):3.65 (min)
Hardness (R45N):77 (min)
Flexural Strength (Mpa):240 (min)
Abrasion By Rubbing (g):0.1 (max)
RUBBER SPECIFICATIONS
Hardness (Shore ‘A’):65+/-5
Density (g/cc):1.12 to 1.17
Tensile Strength (Mpa):20.0 (min)
Elongation (min):400% (min)
Abrasion (mm3):120 (max)
Specification
item | value |
Place of Origin | China |
Liaoning | |
Brand Name | han'peng |
Model Number | 河畔56 |
Processing Service | Moulding, Cutting |
Product Name | Conveyor Transfer Chute Abrasion Wear Resistant Ceramic Rubber Liner |
Material | rubber + ceramic |
Application | Industrial Usage |
Size | Customer Size Accepted |
Usage | Industrial Production |
Feature | Durable |
MOQ | 100pcs |
Sample | Avaliable |
Advantage | Long Life |
Package | 100pcs/pallet |
Packing & Delivery
High Wear Resistant Ceramic Rubber Plate Ceramic Liner packing details:
1.standard sea delivery or air delivery packing.
2.cartons on pallets.
3.1X20' GP: 23 pallets, less than 26,000 KGS
5. Special packing requirements should be known in advance.
1.standard sea delivery or air delivery packing.
2.cartons on pallets.
3.1X20' GP: 23 pallets, less than 26,000 KGS
5. Special packing requirements should be known in advance.
Company Profile
Hanpeng Material rubber Industry (Liaoning) Co., Ltd. is a collection of industrial and mining products research and development,production, sales, technology, service in one of the enterprises, the main products are rubber coating, buffer press, cleaner, cold repair materials, hot curing materials, corrosion resistant coating, wear-resistant ceramic rubber plate, industrial repair agent. The company has advanced production and inspection equipment, products are concentrated in mining equipment and transportation system maintenance and protection.
The company has a strong technical force, with a group of professional talents in the field of chemical chemicals. We focus on research development and production .
At the same time, the company has established technical cooperation with several scientific research institution and universities, and has extensive communication and cooperation in field of practical chemical industry and chemical analysis .With high-end reliable products and technical solutions which Lower maintenance costs and longer life significantly for delivery system , the products are widely used in mining, cement, electricity, metallurgy, port, machinery, petrochemical, building materials and other industries.
The company adheres to the principle of quality first, customer first, to provide our customers with conveyor belt maintenance, anti-corrosion and anti-wear products and services by the growing marketing and service network, and strive to create the first-class brand in domestic conveyor belt maintenance.
The company has a strong technical force, with a group of professional talents in the field of chemical chemicals. We focus on research development and production .
At the same time, the company has established technical cooperation with several scientific research institution and universities, and has extensive communication and cooperation in field of practical chemical industry and chemical analysis .With high-end reliable products and technical solutions which Lower maintenance costs and longer life significantly for delivery system , the products are widely used in mining, cement, electricity, metallurgy, port, machinery, petrochemical, building materials and other industries.
The company adheres to the principle of quality first, customer first, to provide our customers with conveyor belt maintenance, anti-corrosion and anti-wear products and services by the growing marketing and service network, and strive to create the first-class brand in domestic conveyor belt maintenance.
FAQ
1. who are we?
We are based in Liaoning, China, start from 2021,sell to Domestic Market(50.00%),South America(30.00%),Western Europe(10.00%),Southeast Asia(3.00%),Mid East(2.00%),Southern Europe(2.00%),Northern Europe(2.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Rubber repair strip,Diamond patch,Quick repair adhesive,rubber plate,Ceramic rubber sheet
4. why should you buy from us not from other suppliers?
We are a collection of industrial and mining products research and development, production, sales, technology, and service , The company has advanced production and inspection equipment,Our products are unique and recognized by our customers.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union;
Language Spoken:English,Chinese
We are based in Liaoning, China, start from 2021,sell to Domestic Market(50.00%),South America(30.00%),Western Europe(10.00%),Southeast Asia(3.00%),Mid East(2.00%),Southern Europe(2.00%),Northern Europe(2.00%). There are total about 51-100 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Rubber repair strip,Diamond patch,Quick repair adhesive,rubber plate,Ceramic rubber sheet
4. why should you buy from us not from other suppliers?
We are a collection of industrial and mining products research and development, production, sales, technology, and service , The company has advanced production and inspection equipment,Our products are unique and recognized by our customers.
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C,MoneyGram,Western Union;
Language Spoken:English,Chinese
