Made by Schneeberger machine Harmonic disc type straight tooth carbide gear shaper cutter
- Category: >>>
- Supplier: Chongqing Fubang Tools Manufacturing Co. Ltd.
Share on (1600716619390):
Product Overview
Description
Product Description
module&DP chamfer Taper shank straight tooth gear shaper cutter with S390 raw material
mainly made with Powder metallurgy steel, our products are mainly used for reducer, harmonic reducer, auto gear, wind power gear ring, etc.
All the products are customized according to customers working part drawing, we need know your products drawing first then we make suitable cutters according to the drawing.
The cutters we can make customization for you as below
Specification
Gear cutter type | Type of construction | ||||
straight tooth | taper shank | feeler、chamfer、R-DOUBLE、R、top cut、protuberance/pre-shaving、pre-grinding、sprocket、triangular spline、rectangle spline、harmonic | |||
disk-type | |||||
calathiform/ bowl-type | |||||
helical tooth | taper shank | feeler、chamfer、R-DOUBLE、R、topcut、protuberance/pre-shaving、pre-grinding、sprocket、triangular spline、rectangle spline、harmonic | |||
disk-type | |||||
calathiform/ bowl-type | |||||
Application
Internal gear ring
Step flower key shaft head gear
Helical Teeth connet to step joint
External teeth gear with step
External teeth gear in the middle of the axis
Internal rectangle shaped gear
Company Profile
Office overview
How can we make high accuracy Gear shaper cutters?
Customer's drawing DWG file
Firstly, we need check customer's work piece drawing
Our engineers make drawing according to customers work piece drawing
envelope diagram to check if it is suitable for this design..
The machines we use for high accuracy cutters processing.
The machine is manufactured by Swiss Schlierberg machine Tool Manufacturing Company, which has 115 years of manufacturing history of high-precision tool grinders for various types of gear shaper grinding.The precision dimension stability of this equipment is very excellent in the grinding of cutter profile, and the profile size can meet the DIN AA grade standard.
Teeth precision detection steps
1, system reset, 2, read parameters, 3, replace probe, 4, probe calibration, 5, set the height, 6, start measuring, 7, according to the prompts, 8, complete the measurement to replace the product.
1. System reset; 2. Read parameters; 3. Replace probe; 4. Probe calibration; 5. Set the entry height; 6. Start measurement 7.Complete measurement and replace products.
