Outdoor Waterproof Digital Signage 65 Inch 2500 Nits Sunlight Readable LCD Monitor
- Category: >>>
- Supplier: Shenzhen Fengshi Technology Co. Ltd.
Share on (1600716688015):
Product Overview
Description
65 inch outdoor lcd advertising screen | ||||||
MODEL | OD650H25 | |||||
Panel | Diagonal Size | Class | 65 | |||
Measured | 64.53" / 163.9cm | |||||
Resolution | 3840x2160 (16:9) | |||||
Pixel Pitch(mm) | 0.372 x 0.372 | |||||
Active Display Area(mm) | 1428.48(H) x 803.52(V) | |||||
Brightness(Typ.) | 2500cd/m2 | |||||
Contrast Ratio | 1200:1 | |||||
Viewing Angle(H/V) | 178/178 | |||||
Display Colors | 8 bit – 16.7M | |||||
Color Gamut | 72% | |||||
Operation Hour | 7*24 | |||||
Haze | 1% | |||||
Display | Dynamic C/R | 100,000:1 | ||||
Sound | Speaker Type | N/A | ||||
Power | Power Supply | AC 100 – 240 V~ (+/- 10 %), | ||||
50/60 Hz | ||||||
Max[W/h] | 298 | |||||
Mechanical Spec | Dimension (mm) | Set | 1500.2 x 875.0 x 95.7 mm | |||
Package | 1620 x 1120 x 460 mm | |||||
Weight (kg)Set | Set | 60.0kg | ||||
Package | 96.0kg | |||||
Mounting Hole | 1389 x 560 (Basic) | |||||
1400 x 400 (VESA Brack-et Option) | ||||||
Protection Glass | 5mm | |||||
Bezel Width (mm) | 33.8 / 33.8 / 33.8 / 33.8 mm | |||||
Operation | Operating Temperature | -30℃~ 50℃ | ||||
Humidity | 10~100% (Non-condensing) | |||||
IP Certificate | IP56 | |||||
Internal Player (Embedded H/W) | Processor Coretex | Rockchip RK3288 Coretex A17 1.8GHz | ||||
Memory Interface | HYNIX DDR3 2GB | |||||
Storage | 8GB | |||||
Operating System | Android 7.1 | |||||
Multimedia Video Decoder | MPEG-1/2/4, H.264, WMV,WKV,TS,FLV | |||||
JPEG, PNG, BMP, PNG,GIF | ||||||
MP3 | ||||||
Customized 65 inch indoor semi-outdoor high brightness advertising display lcd digital signage monitor screen
FSOD650-L is full outdoor lcd display, self-contained outdoor displays that are certified to withstand the elements and provide excellent visibility around the clock, in any light. High brightness lcd display are fully equipped for outdoor placements and feature an innovative cooling system so there’s no need for a supplemental heating or air conditioning unit. All in an ultra-slim design with an embedded power box and durable Magic Glass that protects against vandalism and graffiti.
Product Description
Applications
Hot sale
If you want to know more new products, please contact us >>
Company Profile
It is a high-tech enterpris specializing in the research and development of high brightness LCD modules.Has more than 10 years of experience in the design of LED high-brightness LCD modules and application experience of outdoor LCD displays.
With our own 10,000-class dust-free workshop(equipped with shower and cargo shower room),professional optical transmittant tester,color brightness meter Top-con BM-7,electrical safety integration tester,vibration test bench and so on.
Now we have 15”-98”LCD panel with brightness of 500-5000nits.We offering OEM/ODM service according to the size and brightness of customers’ needs.Special launch 4K high brightness LCD panel,ultra high brightness LCD panel.
Fengshi technology independently designed the full metal structure of the high brightness LCM with good thermal
conductivity,straight edge structure and better brightness uniformity. Combined with a new generation of high brightness and energy-saving backlight modules.Our products have been exported to more than 60 countries and regions in the world.
With our own 10,000-class dust-free workshop(equipped with shower and cargo shower room),professional optical transmittant tester,color brightness meter Top-con BM-7,electrical safety integration tester,vibration test bench and so on.
Now we have 15”-98”LCD panel with brightness of 500-5000nits.We offering OEM/ODM service according to the size and brightness of customers’ needs.Special launch 4K high brightness LCD panel,ultra high brightness LCD panel.
Fengshi technology independently designed the full metal structure of the high brightness LCM with good thermal
conductivity,straight edge structure and better brightness uniformity. Combined with a new generation of high brightness and energy-saving backlight modules.Our products have been exported to more than 60 countries and regions in the world.
Quality Control
Certifications
FAQ
1. Q: Are you a manufacturer or trading company?
A: We are a professional manufacturer specialized in LCD panel/LCM since 2016 located in Shenzhen.
2. Q: How long is the warranty of 55 inch custom outdoor advertising lcd display large outdoor tv totem outdoor digital signage?
A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements. In order to support different
customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA, DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.
4. Q: What brand of screen do you use?
A: Original LG/SAMSUNG/AUO etc. screen, we can guarantee each display will pass through strict quality inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity & the RLSM028BD report, ISO certification, FCC certification, UL certification.
6. Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black over 110℃.
7. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
8. Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
A: We are a professional manufacturer specialized in LCD panel/LCM since 2016 located in Shenzhen.
2. Q: How long is the warranty of 55 inch custom outdoor advertising lcd display large outdoor tv totem outdoor digital signage?
A: Our officially promised warranty time is 1 year or 18months(Non-artificial damages) from the date of delivery.
3. Q: Do you provide ODM/OEM or customized service?
A: We’re BOE High-bright LCD ODM factory, OEM/ODM are available based on your requirements. In order to support different
customers, we are able to supply:
(1) High Brightness LCD Panel: LCD panel+led driver board+auto dimming sensor
(2) Open Frame LCD Displays: LCD Panel+PSU+AD board(optional interface, eg: HDMI, VGA, DVI, USB...)+Touch optional
(3) Window Facing Displays: LCD Panel+PSU+AD board (network board optional)+fan system+temperature control board+housing
(4) Full Outdoor Displays: customized. eg: touch function, IP55/IP65 etc.
4. Q: What brand of screen do you use?
A: Original LG/SAMSUNG/AUO etc. screen, we can guarantee each display will pass through strict quality inspection.
5. Q:What certifications you have?
A:The CE-EMC Certificate of Conformity & the RLSM028BD report, ISO certification, FCC certification, UL certification.
6. Q:What is the temperature when the screen surface goes black?
A: Normal grade goes black over 68℃；industrial grade goes black over 110℃.
7. Q: What is the MOQ?
A: Sample testing is acceptable, the price is negotiable for bulk order.
8. Q: When will you delivery?
A: High brightness LCD panel sample order shipped in 3days, bulk order shipped within 2 weeks.
