Product Overview
Description
Bag filters includes single-bag filters, multi-bag filters, and multi-bag filters. The filter bag material has different filter materials, and each has its own different filtration methods, filtration efficiency, and filtration accuracy. Using the same filter material, the filtering effect will change when the temperature, viscosity, flow rate or quality of the filtrate and impurity content of the filtrate change.
Description of the product
Bag filters includes single-bag filters, multi-bag filters, and multi-bag filters. The filter bag material has different filter materials, and each has its own different filtration methods, filtration efficiency, and filtration accuracy. Using the same filter material, the filtering effect will change when the temperature, viscosity, flow rate or quality of the filtrate and impurity content of the filtrate change. Please select the appropriate filter material according to the actual working conditions. Multi-bag filter bag The material has excellent chemical stability and heat resistance, and has reached a high level in terms of filtration efficiency and filtration accuracy. Commonly used multi-bag filter bag materials include PE, PP, PTFE, PMIA, NMO, etc.
Product details (core components)
The larger treatment capacity is the reference value when treating water, the actual value will be different due to the change of liquid viscosity, impurity content and pressure difference
Filters made of stainless steel, 304 stainless steel, 316L stainless steel and plastic are available
Provide various O-rings of different materials to meet the needs of different fluids and working temperatures
The locking method of the filter cover can be made into a hoop type, a buckle type, and a ring type
Specification
| Model | Bag model | Bag qty | Flow area (m2) | Max flow (m3/h) | Pressure (Mpa) | Caliber |
| SGD-S2 | 2 | 2 | 0.9 | 50 | 1 | 2-1/2" |
| SGD-S3 | 2 | 3 | 1.35 | 75 | 1 | 3" |
| SGD-S4 | 2 | 4 | 1.8 | 100 | 1 | 4" |
| SGD-S5 | 2 | 5 | 2.25 | 125 | 1 | 5" |
| SGD-S6 | 2 | 6 | 2.7 | 150 | 1 | 6" |
| SGD-S8 | 2 | 8 | 3.6 | 200 | 1 | 6" |
| SGD-S9 | 2 | 9 | 4.05 | 225 | 1 | 8" |
| SGD-S10 | 2 | 10 | 4.5 | 250 | 1 | 8" |
| SGD-S12 | 2 | 12 | 5.4 | 300 | 1 | 10" |
| SGD-S16 | 2 | 16 | 7.2 | 400 | 1 | 12" |
| SGD-S18 | 2 | 18 | 8.1 | 450 | 1 | 12" |
| SGD-S24 | 2 | 24 | 9 | 600 | 1 | 12" |
| Accuracy: 0.1, 0.2 .0.3 , 0.5, 1 , 5, 10, 15, 25, 50, 100, 200, 300, 400, 500, 600 Microns | ||||||
How does it work
The bag filter consist of housing, supporting basket and filter bag,the filter bag inside is supported by a metal mesh basket. The liquid flows in from the inlet and flows out from the outlet after being filtered by the bag filter. Impurities are intercepted in the filter bag and can be used after replacing the filter bag. Through the filter bag, under the action of pressure, the original liquid will pass through the filter bag. The contaminants intercepted by the filter bag will be trapped in the filter bag and the filter residue will be left in the filter bag. Purpose. The bag filter is often installed after the pressure filter to remove fine particles in the liquid to meet the water intake requirements of the subsequent process.
Product advantages
Bag filter is a kind of multi-purpose filter equipment with novel and reasonable structure, good sealing performance, strong circulation capacity, simple operation, wide application range and strong adaptability. The bag filter has a low probability of side leakage of the filter bag, can accurately ensure the filtration accuracy, and can quickly replace the filter bag, basically no material consumption for filtration, which reduces the operating cost.
Product application
Mainly used for the filtration of paint, beer, cosmetics, vegetable oil, electroplating solution, milk, industrial water, latex, sugar water, fruit juice, vinegar, resin, ink, and industrial wastewater
FAQ
• 1.IS YOUBIOU (UBO) Factory or Trading Company?
YOUBIOU (UBO )Group has our own factory. professional on wedge wire and filters production and export for more than 10 years.
• 2.HOW ABOUT THE MOQ?
MOQ according to different product, sometimes MOQ decided by customer.
• 3.Cou You supply the sample?
We could offer the sample for free charge but the cost of freight is extra.
• 4. What payment term do you accept?
T/T ,L/C at sight, Western Union, and other mainstream payment term.
• 5. How about the delivery time?
Usually within 3-15days after receiving the deposit;
• 6.Where is your Market?
We have been exporting to more than 120 different countries and regions all over the world.
• 7.How About your sales service?
Market promotion support and best after sales service will be offered to every customer, and help them get more new customers and orders.
