PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size

PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size

Share on (1600720828933):


Price:$8,000.00 - $9,000.00

Quantity:


Product Overview

Description



Product Description




PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size
PVC Card Laminating Machine Hot Lamination Machine ID card Lamination Machine A3 A4 size




Model No.
ST-115FA3 350x500
ST-215MA3
350 x 500
ST-115B 420 x 520
ST-215H 350 x 500
Output per hour
2000-2500 cards
2000-2500 cards
1440-2000 cards (3x8 Layout)
1920-2600 cards (4x8 Layout)
3150-4500 cards (3x7 Layout)
3800-5000 cards (5x5 Layout)
Heat cool structure
Single tower
Double towers
Single tower
Double towers
Control method
Normal electrical
Normal electrical
PLC automatic
PLC automatic
Press plate size(mm)
350 x 500
350 x 500
420 x 520 (350x500 customizable)
350 x 500
For cards layout
3x7 or 3x8
3x7 or 3*8
4x8, 3x8, 5x5
3x7, 3x8, 5x5
Press plate material
Default standard is No.45 steel, Optional aluminum alloy
Opening QTY
Upper 3 heat +
Lower 3 cool
Right 3 heat + Left 3 cool
Upper 3 heat + Lower 3 cool
(3 heat + 3 cool customizable)
Right 5 heat + Left 5 cool (6+6, 7+7 customizable)
Opening space
48 mm
48 mm
50 mm
50 mm
Sheets in 1 opening
About 10 layers
Pressure method
Hydraulic
Cylinder QTY & diam.
1x140 mm
2x140 mm
4x100 mm
8x90 mm
Cylinder stroke
320 mm
180 mm
240 mm
280 mm
Oil tank capacity
50 L
50 L
150 L
150 L
Hydraulic Oil Grade
No. 46 anti-wear hydraulic oil
Hydraulic pressure
2-15 MPa
2-15 MPa
0.8-15 MPa
0.8-15 MPa
Pressure accuracy
±1.0 MPa
±1.0 MPa
±0.3 MPa
±0.3 MPa
Pressure grade
Cannot graded
Cannot graded
1-4 grades
Heat pressure can set 1-8 grades; Cool pressure can set 1-4 grades
Pressure buffer spring
No
No
Yes
Yes
Heating method
Electric heating tube
Heating temperature
≤250°C
≤250°C
≤250°C
≤250°C
Temperature accuracy
±2.0°C
±2.0°C
±1.0°C
±1.0°C
Cooling method
Water circulation cooling
Cooling tool
3 HP water chiller,
or use water bucket
3 HP water chiller,
or use water bucket
5 HP water chiller
8 HP water chiller
Power
11.1kW
11.1kW
13 kW
22 kW
Power supply
AC380V or 220V 50/60HZ
AC380V or 220V 50/60HZ
AC380V 50/60HZ
AC380V 50/60HZ
Machine Dimension
800 x 700 x 1750 mm
1500 x 800 x 1600mm
1600 x 1000 x 1400 mm
2200 x 1000 x 1500 mm
Machine weight
800 KG
1000 KG
1800 KG
3000 KG








Recommend Products


425×520mm 5 opening Hot and cold PVC card fusing machine
3x7/8/9/10 PVC card punching machine


PVC card hologram foil hot stamping machine
Special shape PVC card Punching Machine


Contact us




Packaging & Shipping


PACKAGING


 Packaging Details
Stong wooden box package
                                     Port
The main ports in China, depends customers choice

Lead Time
 1 pc
35 days
 >1 pcs
To be negotiated




SHIPPING
1.By air, sea or combined transportation.
2.Express via FEDEX, TNT, UPS, DHL, EMS(AS your request)
3.Tracking Number will offer you immediately after delivery
4.Shipping cost depends on the shipping method, product quantity,weight, carton size and your area.




Company Profile












Certificate




FAQ


Q1: Are you a manufacturer ?
Yes.We are a professional manufacturer of machine for more than15 years.
Q2:Can your machine be customized?
Yes, almost all of our products can be customized, including the sizes,color, logo, package and so on.
Q3: How about your package?
A: Our machines are well wrapped by plastic film to be water proof first, then loading and fixing in a plywood case. If by
FCL(full container loading) we might use the wooden case.
Q4:How do you ship the finished products?
By Sea, By Plane, By courier, TNT , DHL, Fedex, UPS Etc.
Q5:What's the delivery time?
Within 15-35 days after get the payment
Q6: What is your after sale service?
A: Any questions will be responded within 24 hours by email, Skype, call or Whatsapp/Wechat. In addition, we have professional engineer available for overseas service...
Q7:Does it easy to operate and what can ido if it doesn't work?
First, our machine is stable and easy to operate by one man. What you do is just learn some basic thing like loading the jumbo roll paper, start the machine and cutting the paper. And we will sent you manual and video.we suggest you to come to visit our factory to learn more thing by yourself , and if there is something goes wrong,you can call us video-chat email us. And we will give solutions within 36 hrs.
Q8:If the machines spare parts broken,where can I get ?
We will give you the spare parts which is vulnerable, and some critical parts like gear box our quality is good, in case it broken within one year ,we will sent you for free.
