Product Overview

Description







NGINE: 1GD-FTV 174 HP 3400 rpm Torque 310 lb.-ft. 2,600 rpm
TRANSMISSION: RC61F, Manual 6-speed
DRIVETRAIN: 4x4
TECHNICAL SPECS
- Start: Key
- Displacement (L): 2.8
- Number of cylinders / configurations: 4 in line
- Compression ratio: 15.6:1
- ETCS-i (Electronic Throttle Control System-intelligent)
- D4-D with Common Rail (Direct fuel injection by common high-pressure pipeline)
- Variable Geometry Turbocharger with Intercooler (Intercooler)
- Traction: Transfer case reducer
- Front suspension: Independent, double fork type with springs elastic element and stabilizer bar
- Rear suspension: Dependent, rigid shaft type with springs elastic element (above the shaft)
- Chassis: Body on frame construction
- Brakes: Ventilated Disc (front)/ Drum (rear)
- Hand parking brake
- Assistance: Hydraulic, HAC (Hill Assist Control) and Cruise Control
EXTERNAL DIMENSIONS
- Total height (mm): 1,815
- Total width (mm): 1,815
- Total Length (mm): 5,335
- Distance between axis (mm): 3,085
- Ground clearance (mm): 310
- Turning diameter (m): 11.8
- Front forward (mm): 1,495
- back gage (mm): 1,550
- Input angle: 31
- Output angle: 26
DIMENSIONS OF THE PAN
- Height (mm): 480
- Width (mm): 1,540
- Length (mm): 1,525
- Volume of cargo (m3): 1
WEIGHT AND CAPACITY
- Fuel tank capacity (liters): 80
- Vehicle weight (kg): 2,065
- Gross Vehicle weight (kg): 2,910
- Load capacity (kg): 845
- Cargo volume with folded seats: 600



•








•



































































































































































































































  SPECIFICATION
  MODEL NAME	Toyota Hilux Revo
  GRADE	G
  DRIVE TRAIN	4WD
  SEATING CAPACITY	5
  TRANSMISSION	6 AT
  Weight & Dimension
  Overall Length (mm)	5330
  Overall Width (mm)	1855
  Overall Height (mm)	1815
  Wheelbase (mm)	3085
  Ground Cleanrance (mm)	310
  Curb Weight (kg)	2055-2095
  Gross vehicle weight (kg)	2910
  Chasis
  Suspension Front / Rear	Double Wishbone/Leaf spring Rigid Axle
  Brake Front / Rear	Ventilated Disc/Leading-Trailing (Drum Brake)
  Minimum turning radius Tire / Body (m)	6.4/6.7
  Fuel Tank Capacity	80L
  Tire and Disc Wheel	265/60 R18 AL
  Engine & Transmission
  Engine Type	1GD-FTV (2.8L-DIESEL)
  Piston Displacement (cc)	2755
  Max. Output (kw(bhp)/rpm	130 (175)/3400
  Max. Torque Nm/rpm	450 /1600 - 2400
  Fuel System	Fuel Injection with Common rail
  Safety
  SRS Airbags	9 SRS Airbags
  Braking System	ABS, BA, VSC, HAC, DAC, TSC, A-TRC, EBD, EBS, BOS
  Fire Extinguisher	-
  Multi Terrain Selection System	-
  Exterior
  Daytime Running Light System	WITH
  Clearance And Back Sonar	-
  Roof Rack & Roof Rail	-
  Headlamp Leveling	WITH AUTO
  Headlamp Cleaner	-
  Auto And Easy Closer Door	-
  Headlamp	LED Projector
  Door Outside Handle	CHROME P-KEY CYL LESS
  Windshield Glass	GREEN LAMINATED TOP SHADE
  Outside Rear View Mirror	CHROME ELEC+RET+S/T
  Interior
  Illuminated Entry System	IG KEY +ROOM LAMP
  Front Seat Vertical Adjuster	POWER ADJ (D ONLY)
  Moon Roof	-
  Speedometer	HI KM/H
  Anti-theft System	IMMOBI+HORN
  Inside Rear View Mirror	DAY & NIGHT
  Front Seat	SEPARATE HIGH
  Seat Material	LEATHER
  Air Conditioner	AUTO A/C
  Wireless Door Lock	WITH SMART+ ANS BCK
  Engine Coolant	LLC 40%
  Cruise Control	•
  Audio	DISPLAY AUDIO DVD wireless + USB + AUX (WITH VIDEO) + 6 SPEAKER (DOOR + TWEETER) + REAR VIEW CAMERA
