LNA never quits 500cc shock absorber buggy
- Category: >>>
- Supplier: Wuhan,Lna,Machinery,Equipment,Co.,Ltd.
Share on:
Product Overview
Description
Product Description
Specification
Model Number | LNA-G500 | Engine | 500cc 4x4 |
Size | 3035*1685*2400mm | Top speed | 80-90 km/h |
Clutch | Automatic | Start | Electric |
Wheelbase | 2400mm | Cooling | Water cooled |
Weight | 395 kg | Max weight load | 200-300kg |
Front track | 278 | Rear track | 177 |
Battery | 12v,18AH | Fuel Tank | 20L |
Brake | Hydraulic Disc Brake | Front wheel | 25*8-12 |
Rear wheel | 25*10-12 | Ground clearance | 320mm |
Color | Black,Green,Red etc | Packing size | 5CBM |
Engine model | single cylinder 4 stroke | Max weight load | 300kg |
Idel speed | 1300/rpm | Carburetor | CV Type |
Braking distance | Less 7m/30km/h | Transmission | Shaft |
Compression ratio | 10:1 |
Detailed Pictures
4x4 Transfer box in front
Real 4x4 provides powerful off road capacity
4x4 Transfer box in Rear
With independent suspensions
The top luggage rack with 4 extra off road lights
The top luggage rack provides roomy space for the bags and belongings, and the extra 4 off road lights provides much better view when ride in the night
LED and Switches of the lights
Strong frame provides much more safety when drive
Hydraulic Disc Brake
Brake is important,we use Hydraulic Discs Brakes only
Certifications
Product packaging
Packing Picture
The packing is made by steel frame with carbon box and covered by plastic. strong enough for the transport.
