2023 Новое поступление, окно с плоской крышкой, 50000 галлонов, комбинированная барабанная система фильтров для пруда koi

Share on:

Price:700,00 $ - 1 375,00 $
Price in USD:Details


Product Overview


Product Description

New upgrade version

Water flow:
Working Power:
Media  Capacity
Inlet /Outlet
15m3/h =
3962 gallon/h
K5 media
105.33 L
Materials: SS 316
Mesh Size: 70μm
1200*600*750 (mm)
4.33 inch = 110mm
18m3/h =
4755 gallon/h
K5 media
119.67 L
4.33 inch = 110mm
23m3/h =
6075 gallon/h
K5 media
1400*640*790 (mm)
4.33 inch = 110mm
27m3/h =
7132 gallon/h
K5 media
1500*660*810 (mm)
4.33 inch = 110mm
32m3/h =
8453 gallon/h
K5 media
1600*680*830 (mm)
 4.33 inch = 110mm
37m3/h =
9774 gallon/h
K5 media
213.56 L
1600*680*830 (mm)
4.33 inch = 110mm

* If you need to customize or more details, please send an inquiry to us

Swage outlet
Our design allows particulate matter to be removed more smoothly.
SS 316 Rotary Drum Filter
SS 316 material Screen and roller are more durable
UV Lamp
15 W UV Lamp removes some harmful algae

Bio Tank with K5 Media.
We fill each one with enough K5 media in the bio-filter section
We use a good quality motor, the normal working condition of the service life can reach 3 years
Control Box with Aviatioin Plug
In order for you to install it, we also provide you with an electric control box with aviation plug.

Customer Photos

One Month Change:

Installation Instructions

How to install?

Gravity system:
We always recommend setting up the filter in gravity. The filter is placed at water level and will then protrude approximately
11-14 cm above the water level. Due to the effect of gravity, your filter fills up with water. A pond pump moves the water from
your filter back to the pond.

Feding-Pump system:
If you choose feeding-pump system, you need to consider these things. First, feeding-pump system will reduce the capacity of Combi Drum Filter. Take a loss of 30% into account.For example,a YCM-03 can handle a maximum of 16.1m3 per hour in gravity setup, and a feeding-pump system a maximum of 16.1m3.There is also a reduction in the capacity of the biological filter section, for example, the YCM-03 will be reduced to 95.5L from 135.11 L of K5 media biological material.

Recommend Products


Packing & Delivery


Company Profile

Qihang is a trade company, as well as a manufacturer. We not only provide products, but also good service and solutions for our customers. Our sales team both have 2-3 years experience.
Our R&D team is developing new products. 3 or more new products will be pushed to the market.
Our production lines have high efficiency. The annual output is 60,000 sets per year.
The main products include ozone generator, oxygen concentrator, ozone tester, ozone spare parts, drum filter, protein skimmer, BIO filter, PP tank, temperature control system, UV lamp, oxygen cone and etc.


Q: Are you manufacturer or trader?
A: We’re professional manufacturer focus on ozone equipment, located in Baiyun District,Guangzhou City, China. Welcome to visit us.

Q: What’s the warranty?
A: Warranty is 12 months, life time technical support. If any quality problem occur during this period,which due to our responsibility, we’ll take care of it, or send more new spare parts to replace.

Q: What’ the MOQ?
A: One piece each model.

Q: Can I buy a sample for test purpose, then if it’s ok, I’ll buy more?
A: Yes, you can.

Q: Can we print our logo and have our own package
A: Yes, you can, OEM&ODM orders are acceptable.

Q: Is there any discount?
A: Of course, more quantities, more discount.

Q: Can I get a catalog?
A: Yes, you can download on our website.

Q: How is the quality?
A: All the materials used for our products are strictly chosen by QA, finishings are checked carefully by QC. Every machine will be strictly tested and aged for several days before delivery.
