CHINT miniature circuit breaker NB1Z 63 1p 2p low voltage modular DIN rail motor protection 1A 63A 6kA DC60V DC125V DC220V
CHINT miniature circuit breaker NB1Z-63 1p 2p low voltage modular DIN rail motor protection 1A-63A 6kA DC60V DC125V DC220V
CHINT miniature circuit breaker NB1Z-63 1p 2p low voltage modular DIN rail motor protection 1A-63A 6kA DC60V DC125V DC220V
CHINT miniature circuit breaker NB1Z-63 1p 2p low voltage modular DIN rail motor protection 1A-63A 6kA DC60V DC125V DC220V
CHINT miniature circuit breaker NB1Z-63 1p 2p low voltage modular DIN rail motor protection 1A-63A 6kA DC60V DC125V DC220V
CHINT miniature circuit breaker NB1Z-63 1p 2p low voltage modular DIN rail motor protection 1A-63A 6kA DC60V DC125V DC220V
CHINT miniature circuit breaker NB1Z-63 1p 2p low voltage modular DIN rail motor protection 1A-63A 6kA DC60V DC125V DC220V

CHINT miniature circuit breaker NB1Z 63 1p 2p low voltage modular DIN rail motor protection 1A 63A 6kA DC60V DC125V DC220V

Share on (1600724152297):


Price:

Quantity:


Product Overview

Description


NB1Z-63 AC/DC miniature circuit breaker is for the line with voltage no more than DC 220V or AC 230/400V. The rated current region is from 1~63A. It s major function is to protect the line from over load and short circuit. It is widely used in industrial, commerical, high building, and private home etc. It is high quality which meet the IEC60898-2 standard.





Specification:


Model: Chint NB1Z-63


Rated value (V): 1P: AC230/400,DC220; 2P:AC400, DC220


Rated current(A): 1,2,3,4,6,10,16,20,25,32,40,50,63


Poles: 1P, 2P


Breaking Capacity: 6KA


Tripping type: B, C


Mechainical life: 20000 times


Pollution level: class 2


Protection level: IP20


Standard: IEC 60898-2
