New N9K C93128TX Nexus 9000 Series with 96 PORT 10G T and 8Ports 40G QSFP Core Network Switch
New N9K-C93128TX Nexus 9000 Series with 96-PORT 10G-T and 8Ports 40G QSFP Core Network Switch
New N9K-C93128TX Nexus 9000 Series with 96-PORT 10G-T and 8Ports 40G QSFP Core Network Switch
New N9K-C93128TX Nexus 9000 Series with 96-PORT 10G-T and 8Ports 40G QSFP Core Network Switch
New N9K-C93128TX Nexus 9000 Series with 96-PORT 10G-T and 8Ports 40G QSFP Core Network Switch
New N9K-C93128TX Nexus 9000 Series with 96-PORT 10G-T and 8Ports 40G QSFP Core Network Switch
New N9K-C93128TX Nexus 9000 Series with 96-PORT 10G-T and 8Ports 40G QSFP Core Network Switch

New N9K C93128TX Nexus 9000 Series with 96 PORT 10G T and 8Ports 40G QSFP Core Network Switch

Share on (1600724718968):


Price:$5,200.00 - $5,500.00

Quantity:


Product Overview

Description






Model: N9K-C93128TX


Description:
Nexus 9000 Series with 96p 100M/1/10G-T and 8p 40G QSFP

Specifications:
Switching capacity: 2.56 Tbps
Forwarding rate: 750 Mpps
Port: 96x 10 Gigabit Ethernet RJ45








N9K-C93128TX Overview
N9K-C93128TX is the Nexus 9300 with 96p 100M/1/10G-T and 8p 40G QSFP. The Nexus 9300 platform consists of fixed-port switches designed for top-of-rack (ToR) and middle-of-row (MoR) deployment in data centers that support enterprise applications, service provider hosting, and cloud computing environments. They are Layer 2 and 3 nonblocking 10 and 40 Gigabit Ethernet switches with up to 2.56 terabits per second (Tbps) of internal bandwidth.

Quick Specs


Product Code
N9K-C93128TX
Ports
96 fixed 1/10GBASE-T ports
Supported speeds
100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds
40 Gigabit Ethernet uplink ports
6 or 8 QSFP+ ports active through the uplink module
Physical (H x W x D)
5.3 x 17.5 x 22.5 in.
(13.3 x 44.5 x 57.1 cm)
Weight
32.56 lb (14.8 kg) (without power supplies, fans, or uplink module)


Similar Items Comparison


Product Code
N9K-C9396TX
N9K-C93128TX
Ports
48 fixed 1/10GBASE-T ports
96 fixed 1/10GBASE-T ports
Supported speeds
100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds
100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds
Physical (H x W x D)
3.5 x 17.5 x 22.5 in.
(8.9 x 44.5 x 57.1 cm)
5.3 x 17.5 x 22.5 in.
(13.3 x 44.5 x 57.1 cm)
Weight
22.45 lb (10.2 kg) (without power supplies, fans, or uplink module)
32.56 lb (14.8 kg) (without power supplies, fans, or uplink module)




N9K-C93128TX Specification
Ports
96 fixed 1/10GBASE-T ports
Supported speeds
100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds
40 Gigabit Ethernet uplink ports
6 or 8 QSFP+ ports active through the uplink module
Customers have the choice of either N9K-M6PQ or N9K-M12PQ for 40 Gigabit Ethernet uplink connectivity to aggregation or spine
switches.
100 Gigabit Ethernet uplink ports
Customer can have 100 Gigabit Ethernet uplink connectivity to spine switches or routers through the N9K-M4PC- uplink module, with
CPF2 optics as well as the CPAK 100-Gbps module through converters.
The N9K-M4PC-CFP2 offers 5 MB of additional buffer space for each port.
Power supplies (up to 2)
930W DC, or 1200W HVAC/HVDC
Typical power (AC)
582W
Maximum power (AC)
853W
Input voltage (AC)
100 to 120V (maximum output 800W)
200 to 240V (maximum output 1200W)
Input voltage (HVAC)
200 to 277V
Input voltage (DC)
–48 to –60V
Input voltage (HVDC)
–240 to –380V
Frequency (AC)
47 to 63 Hz
Fans
3
Physical (H x W x D)
5.3 x 17.5 x 22.5 in.
(13.3 x 44.5 x 57.1 cm)
Acoustics
71.4 dBA at 40% fan speed, 80.2 dBA at 70% fan speed, and 85.7 dB at 100% fan speed
RoHS compliance
Yes
Weight
32.56 lb (14.8 kg) (without power supplies, fans, or uplink module)
