Model | F500 2.6 | F500 2.9 | F500 3.9 | F500 4.8 | |||||
Pixel Pitch(mm) | 2.6 | 2.976 | 3.91 | 4.81 | |||||
Pixel Matrix Per Sq.m | 147,456 | 112,896 | 65,536 | 43,264 | |||||
Pixel Configuration | SMD1515/1415 | SMD2121/1415 | SMD2121/1921 | SMD2121/1921 | |||||
Scan | 1/32 | 1/21 | 1/16 | 1/13 | |||||
Brightness (cd/㎡) | 1,000/4,500 | ||||||||
Module Dimension | 250×250mm | ||||||||
Cabinet Dimension | 500x500mm / 500x1000mm | ||||||||
Cabinet Material | Die Casting Aluminum | ||||||||
Cabinet Weight | 7.5KG/15KG | ||||||||
Power Con.(W/㎡) (Max / Avg) | 700W/200W | ||||||||
Service Access | Front/Rear | ||||||||
Refresh Rate (HZ) | ≥3840 | ||||||||
Grey Scale (bit) | ≥16 | ||||||||
Viewing Angle (H/V) | 160°/160° | ||||||||
IP Rate | IP43 / IP65 | ||||||||
Input Voltage (AC) | 110V / 240V | ||||||||
