Product Overview
Description
Products Description
Production Descriprion
Slitting line is mainly used for slitting and cutting coil materials such as tinplate, galvanized iron, silicon steel sheet, cold
rolled steel strip, stainless steel strip, aluminum strip, and steel strip. It cuts metal coils into strips of various widths, and
then harvests the strips into small coils for use in the next process. It is a necessary equipment for precision cutting of metal strips in the transformer, motor industry and other metal strips.According to the thickness of the slitting plate, it is divided into thin plate slitting line and thick plate slitting line.
rolled steel strip, stainless steel strip, aluminum strip, and steel strip. It cuts metal coils into strips of various widths, and
then harvests the strips into small coils for use in the next process. It is a necessary equipment for precision cutting of metal strips in the transformer, motor industry and other metal strips.According to the thickness of the slitting plate, it is divided into thin plate slitting line and thick plate slitting line.
Features
Equipment Structure And Function：
1. Uncoiler: Used To Support The Coil , Bearing 30Tons. By The Support Shaft, Frame And Other Components. Sent To Board The First Artificial Leveling Machine, Leveling Machine Driven By The Coil To Start.
2. Side Guiding: Sheet To Prevent Run-Time Deviation, Both Sides Of The Sheet Width Direction With Vertical Guide Rollers, Guide Roller Frame Fixed To The Respective Sliding Seat, Through The Hand Wheel By The Screw-Nut Fushi Slide In The Lead Column Along The Width Direction, To Accommodate Different Width .
3. 11 Rollers Leveler: Pinch Steel And Steel Plate For Correction. From The Base, Frame, Sliding Seat Rolls, Leveler Rolls 11
(Under 6 On 5 ) , Motor And Other Components To Enhance The Pressure Adjusting Mechanism . By The Motor Drive Gear Reducer, So That The Next Row Of Rollers Are Turning.Adapt To The 2-8mm Thickness, 1800mm Width. Upper Straightening Rolls (5) Electric Lift, Pressure.
4. Cutting: Down To Size After Shear. Mechanical Shears.
5. Materials Sets: Carry On The Plates After Shearing
6. Electric System: System Includes Console , Cabinet.
1. Uncoiler: Used To Support The Coil , Bearing 30Tons. By The Support Shaft, Frame And Other Components. Sent To Board The First Artificial Leveling Machine, Leveling Machine Driven By The Coil To Start.
2. Side Guiding: Sheet To Prevent Run-Time Deviation, Both Sides Of The Sheet Width Direction With Vertical Guide Rollers, Guide Roller Frame Fixed To The Respective Sliding Seat, Through The Hand Wheel By The Screw-Nut Fushi Slide In The Lead Column Along The Width Direction, To Accommodate Different Width .
3. 11 Rollers Leveler: Pinch Steel And Steel Plate For Correction. From The Base, Frame, Sliding Seat Rolls, Leveler Rolls 11
(Under 6 On 5 ) , Motor And Other Components To Enhance The Pressure Adjusting Mechanism . By The Motor Drive Gear Reducer, So That The Next Row Of Rollers Are Turning.Adapt To The 2-8mm Thickness, 1800mm Width. Upper Straightening Rolls (5) Electric Lift, Pressure.
4. Cutting: Down To Size After Shear. Mechanical Shears.
5. Materials Sets: Carry On The Plates After Shearing
6. Electric System: System Includes Console , Cabinet.
Working Process
Specification
Series | Techincal | Parameter |
Product | raw material | Colour coated galvanized steel/ galvanized steel / carbon steel/ hot rolled/ cold rolled |
width | 1500 mm or can be customized according to your request | |
thickness | 0.15-1.5 mm | |
Decoiler with loading car | loading capacity | 10 Tons |
feature | The decoiler is composition by pressure arm, corbel, that can help make the coil turning more stable. | |
work type | Hydraulic type | |
hydraulic motor power | 5.5 kw | |
transmission motor power | 5.5 kw | |
Leveling device and cutting device | shaft diameter | 50 mm |
roller material | Inside 45# steel outside rubber | |
drive motor power | 5.5 kw | |
processing speed | 0-35 m/min | |
roller station | Up: 7 stations Down: 8 stations | |
cutter material | Cr12 | |
Convey table | usage | After shearing, the conveyor conveys the steel strip to the forming system |
power | 1.5 kw | |
Fully automatic stacker | length | 4 m |
width | 1 m | |
motor power | 4 kw | |
PLC control system | language | English/Chinese or as your request |
length tolerance | +-1.5mm/ 3m | |
PLC brand | Delta brand | |
Frequency brand | Delta brand | |
Encoder brand | Omron brand | |
Low-voltage apparatus brand | Schneider brand |
