Жественные 3 серии DLY3-100A силовой передачи детали электромагнитной тормозных сцепления

Share on:

Price in USD:Details


Product Overview






DLY series electromagnetic clutch is a toothed electromagnetic clutch with sliding rings. It is mainly used in mechanical transmission system. It can realize the combination of the driven part and the active part when the relative speed of the main and driven parts is low or zero, so as to achieve the purpose of starting and stopping commutation and positioning. Widely used in metal processing machinery, metallurgical rolling machinery, packaging machinery, medical machinery, food processing machinery, textile printing and dyeing machinery, paper machinery, precision machine tools and other industries.


The clutch can work reliably under the following conditions:

1. The ambient air temperature is 5 ℃+40 .

2. There is no gas or conductive dust that corrodes metals and destroys insulation in a medium without explosion risk.

3. Clutch must work under the condition of lubricating oil.

4. Voltage fluctuation of clutch coil does not exceed rated voltage of + 5% and - 15%.

5. The clutch installation site shall not exceed 200 meters above sea level.

Production Flow


Packaging & Shipping



Company Information


Clients Visit







Q: Why do we choose your company?

A: Quality is the soul of an enterprise. We can provide you with good-quality one way clutches also with good price.

Q: What is the delivery time?

A: For small quality or samll size of clutches, we can deliver upon receiving advance.

     For large quantity or large size, we have to produce 10-15 working days.

Q: Can you supply with sample clutch?

     Of course! We can provide with a sample to your checking quality.

Q: What is the warranty period of the clutches?

     One-year Guarantee.
