220mm durm high quality Blanket auto adjustment roll to roll calender printing press machine 1.6m

Share on (1600727587545):


Price:$2,750.00-3,100.00

Quantity:


Product Overview

Description





220mm durm high quality Blanket auto adjustment roll to roll calender printing press machine 1.6m








Model
220-1600
220-1700
220-1800
Machine size
2270*2370*1450mm
2270*2470*1450mm
2270*2570*1450mm
Heating method
Electric heat pipe heating
Heating tube quantity
2pcs(3000W/pcs)
Diameter of cylinder
220mm
220mm
220mm
The roll surface
with Teflon coating
Power supply
110V/220V/380V
Heating power
6.4kw
6.7kw
7.2kw
Total power
6.8kw
7.1kw
7.6kw
Speed
20-130meter per hour
Temperature range
30-240℃
Width of Blanket
1620mm
1720mm
1820mm
Heat transfer material width
1500mm
1600mm
1700mm
Tension system
3sets
Feeding system
3sets
Take up system
3sets
Conveyor belt
standard
Blanket automatic adjustment
standard
Blanket deviation alarm
standard
Blanket and roller separation function
standard
table size
1500*1762*1030mm
1500*1862*1030mm
1500*1962*1030mm
Blanket adjustment form
auto-adjust
Packing size
2350*900*1650mm
2450*900*1650mm
2550*900*1650mm
Machine weight
480kg
530kg
580kg
Model
270-1600
270-1700
270-1800
Machine size
2360*2460*1540mm
2360*2560*1540mm
2360*2660*1540mm
Heating method
Electric heat pipe heating
Heating tube quantity
2pcs(3000W/pcs)
Diameter of cylinder
270mm
270mm
270mm
The roll surface
with Teflon coating
Power supply
110V/220V/380V
Heating power
6.8kw
7.4kw
8.0kw
Total power
7.2kw
7.8kw
8.4kw
Speed
20-130meter per hour
Temperature range
30-240℃
Width of Blanket
1620mm
1720mm
1820mm
Heat transfer material width
1500mm
1600mm
1700mm
Tension system
3sets
Feeding system
3sets
Take up system
3sets
Conveyor belt
standard
Blanket automatic adjustment
standard
Blanket deviation alarm
standard
Blanket and roller separation function
standard
table size
1500*1762*1030mm
1500*1862*1030mm
1500*1962*1030mm
Blanket adjustment form
auto-adjust
Packing size
2550*980*1740mm
2650*980*1740mm
2750*980*1740mm
Machine weight
580kg
650kg
720kg




















Since in 2005, it has established good relations with many domestic and foreign enterprises. The products sell well all over the country and are exported to Europe, America, Southeast Asia, Middle East, Africa and other regions. They are highly trusted and highly praised by domestic and foreign customers. The company has advanced production and professional technology, R & D team, so that our products can be favored by our customers. After years of development, the company's main products are screen printing machine(oval printing machine, rotary printing machine and so on ), roller heat transfer machine, T-shirt folding machine, Digital printing machine, heat press machine,


Qingdao Pingte Machinery Equipmate Co., Ltd.is a modern enterprise integrating R&D, production, agency and sales. The company has always been "Provide to customers with efficient and high-quality printing machinery" as their mission, focusing on the printing
industry machinery production, and constantly improve their service levels.








01 Are You a Factory Or a Trading Company?
Factory
02 Do You Accept Customize Machine?
Please communicate with us salesperson at first, we can customize machine on us developing ability.
03 What's The Payment Item?
We usually do 50% T/T as deposit, 50% balance payment before shipment. Cash payment, L/C also can accept on old customer.
04 Do You Have Any Certificate?
We have CE certificate and original certificate if you need.
05 What's Your Warranty?
We supply one-year warranty and full time spare parts supplying after warranty.
