New economic 2.3kw AC220V cnc servo driver
- Category: >>>
- Supplier: Hangzhou Mige Electric Co. Ltd.
Share on (1600728836710):
Product Overview
Description
New economic servo driver
Power source
One phase or three phase AC220V -50~+20% 50/60Hz
Three phase
AC220V -15~+10% 50/60Hz
Suitable
environment
Temperature
Using: 0~ 55 Storage: -20~ 80
Humidity
Below 90% RH No dewing
Vibration
Below 0.5G(4.9m/s2)10 ~60 no continue running
Control mode
1. Position control 2. Speed control
3. The speed tries to move 4. JGO movement
Regenerative applies the brake
In sets
Control
characteristic
Speed frequency response
<400HZ
Speed undulation rate
±0.3 (load 0 ~ 100%); <±0.02(power source -15 +10%)
(value corresponds to rated speed)
Velocity modulation ratio
1:5000
pulse frequency
<=600kHz
Control input
1. Servo enables 2. warning elimination
3. Deviation counter nulling operation
4. Instruction pulse prohlibition
Control output
1. servo prepares the output enables
2. servo warning output
3. the localization completes the output
Position control
Input way
1. pulse+ mark
2. CCW pulse/CW pulse
Electronic gear ratio
1~32767
Feedback Pulse
The most 20000 pulse / revolution
Adds and subtracts the fast function
The parameter establishment adds and subtracts the fast time 6-1530ms(0r/min ~1000r/min)
Surveillance function
Rotational speed, Instruction pulse accumulation, Position deviation, motor torque motor electric current, running status
Protection function
Overspeed, main power source pressure, main power owes the pressure, presses the class overload, applies the brake exceptionally, the encoder is unusual, position deviation
Demonstration, operation
6th LED digital tube. Four buttons
Suitable the load inertia
Less than electrical machinery inertia 5 times
Cooling mode | Natural cooling or forced cooling | |
Use environment | occasion | Avoid dust, oil mist and corrosive gas |
| Storage environment | 0℃~+50℃ |
| Maximum ambient temperature | 65℃ |
| ambient humidity | <80RH,Non condensing and non frosting |
Vibration |
| 5.9ms |
weight |
| About 2.5kg |
Company Information
FAQ
Q1. Are you factory?
Yes, we are factory and we produce stepper motor/driver, Servo motor/driver and spindle servo motor for more than 14 years in China. MIGE is our registered brand.
Q2. What are your products can be use to?
A: Our products can be use in CNC routers ,CNC milling machine ,engraving machine, packaging machine, filling machine, cutting machine, printing machine, laser machine, carving machine, labeling machine, textile machine and so on.
Q3: What kind of shipping methods do you use?
A:1)For samples or small batch , air shipping is recommended . (DHL,Fedex,TNT UPS ,EMS or Aramex) ,We will provide the tracking No. Once we get it after we ship out the products.
2)For mass production or big batch, ocean shippinga shipment is recommended .
Q4: What is the lead time of my products?
A: Lead time : For standard samples , 2-5 days will be OK .
For mass production , the lead time depend on the quantities you need .
Q5: What is your warranty time?
A:12 months. And we provide life-long technical service and after-sale service.
