item | value |
Warranty | 1 years |
Customized support | OEM |
Rated Voltage | 12V/24V |
Place of Origin | China |
Guangdong | |
Brand Name | N/A |
Model Number | C202212256 |
Application | CPAP |
Pressure | High Pressure |
Power Source | Electric Blower |
Motor Type | BLDC 3 phase /6 Pulse/2 Pole |
Bearing Type | Ball bearing |
Rotation Direction | Counterclockwise (View from inlet plate side) |
Operating Voltage Range | DC12~27V |
Max.Input Coil Current | 2.0A |
Rated Power Supply Current | 0.7A max (At 2.0kPa,100L/min,DC 24V) |
Rated Power Consumption | 16.8W max |
Rated Pressure | 2.0kPa (At 100L/Min) |
Maximum Pressure | 5.5kPa (At DC 24V, the coil input current is the maximum of 2.0A) |
Rated Air Flow | 100L/min (At 2.0kPa) |
