Reed width | Nominal reed width: 150,170,190,210,230,250,280,340,360,390cm | |
| Effective reed width: nominal reed width reduced by 0-60cm (150-250cm) | |
| Nominal reed width reduction 0 - 80cm (above 280cm) | |
Weaving range | Short fiber: Ne100-Ne5 | |
| Filament: 50D-900D | |
Weft selection | Double-jet, four-jet and six-jet free weft selection | |
Power | Direct control of positioning parking through electromagnetic brake | |
| Super-start motor 3.0Kw (cam opening) 3.7Kw (dobby opening) 6.5Kw (jacquard opening) | |
| Two-hand operation of button switch | |
Weft insertion | Combined main nozzle and auxiliary nozzle | Extension nozzle |
| Use profiled reed | ABS weft brake |
| Auxiliary main nozzle | |
Opening | Negative cam opening: up to 8 heald frames | |
| Crank connecting rod opening: 4 or 6 heald frames | |
| Positive cam opening: up to 8 heald frames | |
| Dobby opening: up to 16 heald frames | |
| Jacquard opening | |
Menstruation | Electronically controlled continuous positive let-off | |
| Single warp beam (reed width below 250cm) | Left and right warp axes and upper and lower warp axes |
| Positive relaxation | |
| Diameter of side plate of warp shaft Ф 800mm | Φ 914， Φ 1000mm |
Coiling | Electronic coiling | Mechanical coiling |
| Weft density range: 25-205 pieces/inch (mechanical winding), 25-300 pieces/inch (electronic winding) | |
| Maximum roll diameter: Ф 600mm (cam, dobby, jacquard opening) Ф 520mm (crank opening) | |
Beat-up | Crank type multi-reed foot beating-up mechanism | |
| Four-link beat-up (narrow width), six-link beat-up (wide width) | |
Measuring length and storing latitude | Vibrating weft storage | Electronic drum weft storage (FDP) |
Weft frame | Floor type 4 bobbins (2 sprays), floor type 8 bobbins (4 sprays) | |
Selvage | Planetary gear type flanging device | |
Yarn end treatment | Edge discarding and coiling 3 roller type | |
Weft cutting | Mechanical scissors | |
Lubrication | The main transmission part is of oil bath type, with manual centralized oil supply | Automatic centralized oil supply |
Parking device | Weft yarn: photoelectric weft detector, double probe | |
| Warp yarn: 6 rows of electrically contacted stop pieces | |
| Others: skein yarn and selvedge yarn break and stop automatically | |
| Parking reason display: display information on the human-machine interface, multi-function four-color light parking display | |
Automation | Control: multi-function microcomputer control system with parameter setting/control/monitoring/self-diagnosis/artificial
intelligence interface | |
| Broken weft finding device: automatic hook finding | |
| Jog slowly through frequency converter (forward and reverse) | |
| Other: monitor output terminal | |
| Memory card system | |
| Automatic control device for weft insertion time (AJC) | |
