34/5000 YR1030 Table lamp battery test internal resistance (1600731503220)

Share on:


Price:$46.00 - $48.00
Price in USD:Details

Quantity:


Product Overview

Description



Product Description




Specification


item
value
Place of Origin
China
Does it contain battery
Yes
Types of machine-powered batteries
One 18650 lithium battery
Machine size
length, width and thickness / 13.5cm*7.3cm*2.5cm
Single box size
Length, width and height / 16.5cm*12.5cm*5cm
Weight
 host ≈ 200g, test rack ≈ 120g, four-pin probe ≈ 43g, clip ≈ 68g, outer packing box ≈ 90g


Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.


Company Profile




The products we sell have been accurately measured and tested. They not only have good accuracy, but also have good service. You can contact us if you have any questions in subsequent use.


YR1035+ battery internal resistance tester is a true four-wire internal resistance tester, which can measure the internal
resistance and voltage at the same time. It can also be used to measure the resistance. The measurement results are displayed on the same screen. This product is suitable for battery configuration, battery performance testing, battery screening and other aspects.The machine structure exquisite, easy to carry, is your ideal electrician, electronic testing machine.




Precision specifications
Format of precision specification: ± ([degree percentage]+[minimum significant digit])


Range※
Maximum resolution
Precision
display mode
20mΩ
0.01mΩ
0.7%+7
22.00mΩ
200mΩ
0.1mΩ
0.5%+5
20.0 mΩ
1mΩ
0.5%+5
2.200 Ω
20Ω
10mΩ
0.5%+5
22.00 Ω
200Ω
0.1Ω
0.6%+5
220.0 Ω


※The range of gear range is 5%-95%, and the error may be greater than the above precision if the range is not within this range(less than 5% range, or greater than 95% range).



Voltage measurement: ±(% reading +% range)


Range
Maximum resolution
Precision
display mode
4V
1mV
0.8%+5
4.400V
40V
10mV
0.8%+5
44.00V


Positive and negative symmetry error ±(0.012% +5 words)
Temperature Drift 100ppm/℃ within normal service temperature (10℃-40℃)
