Nitinol SMA Shape Memory Alloy Wire
- Category: Other Metals & Metal Products >>>
- Supplier: Baoji,Seabird,Metal,Material,Co.,Ltd.
Share on:
Product Overview
Description
Specification
item | Nitinol SMA Shape Memory Alloy Wire |
Application | Actuators |
Thickness | 2.0mm |
Coils | 10kgs |
Technique | Cold drawn |
Ti (Min) | 45% |
Processing Service | Cold work |
Color | polishing surface black surface |
Standard | ASTM F2063-12 |
Supply Status | Full annealed |
Feature | superelastice |
The Max recovery stress | 600 MPa |
Certificate | ISO9001:2015 |
Sample | Avaliable |
Tensile Strength | 1380Mpa |
Key words | Temperature control system couplings |
NITINOL WIRE DESCRIPTION
Nitinol is a nickel-titanium alloy with super elasticity and shape memory properties. Shape memory refers to the ability of
Nitinol to undergo deformation at one temperature, then recover its original, under formed shape upon heating above its
transformation temperature. Super elasticity occurs at a narrow temperature range just above its transformation temperature; in this case, no heating is necessary to cause the under formed shape to recover, and the material exhibits enormous elasticity, some 10-30 times that of ordinary metal.
Nitinol is a nickel-titanium alloy with super elasticity and shape memory properties. Shape memory refers to the ability of
Nitinol to undergo deformation at one temperature, then recover its original, under formed shape upon heating above its
transformation temperature. Super elasticity occurs at a narrow temperature range just above its transformation temperature; in this case, no heating is necessary to cause the under formed shape to recover, and the material exhibits enormous elasticity, some 10-30 times that of ordinary metal.
What is used for ?
* Heat engines
* Resilient glass frames
* Orthodontic arc wire
* Medical devices
* Actuators
* High reliability couplings
* Temperature control system couplings
* Resilient glass frames
* Orthodontic arc wire
* Medical devices
* Actuators
* High reliability couplings
* Temperature control system couplings
NITI PROPERTIES: ANNEALED TYPICAL
Ultimate Tensile Strength: 130 KSI (895 MPA)
Yield Strength (0.2 Offset):
Austenite: 28-100 KSI (195-690 MPa)
Martensite: 10-20 KSI (70-140 MPa)
Elongation: 25-50%
Ultimate Tensile Strength: 130 KSI (895 MPA)
Yield Strength (0.2 Offset):
Austenite: 28-100 KSI (195-690 MPa)
Martensite: 10-20 KSI (70-140 MPa)
Elongation: 25-50%
NITINOL PROPERTIES: TEMPERED TYPICAL
Ultimate Tensile Strength: 275 KSI (1900 MPA)
Elongation: 5-10%
Ultimate Tensile Strength: 275 KSI (1900 MPA)
Elongation: 5-10%
Company Profile
Baoji Seabird Metal Materials Co.,Ltd was established in 2001,which occupies 21000 square meters.It is located in Baoji,Shaanxi ,China.The company is approved by ISO9000 and SGS certification .
It owns complete equipments from the raw material to finished products,such as TWO Vacuum Medium-frequency Induction Furnace,ULVAR,Two-roller Hot Rolling machine,Four-roller Cold Rolling machine,Two units Plate Leveling machine,Three Cutting Machine,Resistance Furnace,Cylindrical Grinder and so on.
Some products have reached the leading position in China. Such as, medical nitinol sheet and wire,especially two-way shape memory alloy sheet and spring ,as well as porous tungsten rod,etc.
We have two scientists in R&D Department. They have 20years experience on researching nitinol products. They all came from the Northwest Institut .This is our competitive power compare with others.
In 2009,our company expanded our business into overseas market ,and cooperated with over 100 companies and Institutes in past 7years,they are from US,UK,Germany,Singapore and so on. We believe we will make a great progress with many customers.And will porvide the more and more higher quality products and service.
It owns complete equipments from the raw material to finished products,such as TWO Vacuum Medium-frequency Induction Furnace,ULVAR,Two-roller Hot Rolling machine,Four-roller Cold Rolling machine,Two units Plate Leveling machine,Three Cutting Machine,Resistance Furnace,Cylindrical Grinder and so on.
Some products have reached the leading position in China. Such as, medical nitinol sheet and wire,especially two-way shape memory alloy sheet and spring ,as well as porous tungsten rod,etc.
We have two scientists in R&D Department. They have 20years experience on researching nitinol products. They all came from the Northwest Institut .This is our competitive power compare with others.
In 2009,our company expanded our business into overseas market ,and cooperated with over 100 companies and Institutes in past 7years,they are from US,UK,Germany,Singapore and so on. We believe we will make a great progress with many customers.And will porvide the more and more higher quality products and service.
Quality Assurance
1. According to globally recognized standard,for example ASTMF.ASTM ASTMB provide third-part inspection reports,ISO Quality
Management System .
2. Visual inspection to check surface quality ,ensuring without flaw.black dot and other defects.
3. We also take Mechanics Performance Testing, Particle size test microscope ,Powder density tester, pressure testing
machine,scanning electron microscope ultrasonic flaw detector by our company before shipping .
4. Chemical composition making sure all chemical components can satisfy customers demands.
5. Mechanical property testing making sure all Nitinol products have satisfying feature before delivery.
1. According to globally recognized standard,for example ASTMF.ASTM ASTMB provide third-part inspection reports,ISO Quality
Management System .
2. Visual inspection to check surface quality ,ensuring without flaw.black dot and other defects.
3. We also take Mechanics Performance Testing, Particle size test microscope ,Powder density tester, pressure testing
machine,scanning electron microscope ultrasonic flaw detector by our company before shipping .
4. Chemical composition making sure all chemical components can satisfy customers demands.
5. Mechanical property testing making sure all Nitinol products have satisfying feature before delivery.
FAQ
Q: Are you a trading company or manufacturer ?
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we can offer the samples for free and freight afforded by buyer.
Q: How can you ensure the products quality?
A: All products are manufactured according to ASTM standard, and we make 100% inspection before shippment also we can prodide the
MTC Test Certification.
Q: Can you print our logo on the products?
A: Yes, we make it by laser printing and carving.
Q: How can i make a quote for your company?
A: Please let me know the Material.Size.Quantity.
Q: What is your terms of payment ?
A: T/T, L/C
For stocks, 100% in advance;
For futures delivery, 30% in advance, the balance before shipping.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. It is 15-30 days to do new batch.
Q: Can you guarantee the prompt delivery?
A: Yes, please don't worried it. We have professional production team to work 24 hours one day.
Please don't hesitate to contac us if you like to know more. Thank you!
A: We are factory.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we can offer the samples for free and freight afforded by buyer.
Q: How can you ensure the products quality?
A: All products are manufactured according to ASTM standard, and we make 100% inspection before shippment also we can prodide the
MTC Test Certification.
Q: Can you print our logo on the products?
A: Yes, we make it by laser printing and carving.
Q: How can i make a quote for your company?
A: Please let me know the Material.Size.Quantity.
Q: What is your terms of payment ?
A: T/T, L/C
For stocks, 100% in advance;
For futures delivery, 30% in advance, the balance before shipping.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. It is 15-30 days to do new batch.
Q: Can you guarantee the prompt delivery?
A: Yes, please don't worried it. We have professional production team to work 24 hours one day.
Please don't hesitate to contac us if you like to know more. Thank you!
