Products Description



Molecular Sieve

JZ-OI9

JZ-OI9 Molecular sieve spheres are designed for industrial or medical oxygen concentrators in PSA system.


Properties
Unit
JZ-OI5
JZ-OI9
JZ-OIL
Type
/
5A
13X HP
Lithium
Diameter
mm
1.6-2.5
1.6-2.5
1.3-1.7
Static Water Adsorption
≥%
25
30
30
Static CO Adsorption
≥NL/kg
28
/
/
Static CO2 Adsorption
≥%
/
19.8
/
Static N2 Adsorption
≥NL/kg
11
8
22
Separation coefficient of N2 /O2
/
/
3.2
6.2
Bulk Density
≥g/ml
0.73
0.62
0.60
Crush Strength
35
25
12
Attrition Rate
≤%
/
0.3
0.5
Package Moisture
≤%
1.5
1
/
Package
Steel Drum
150KG
125KG
125KG


Application







Oxygen Molecular sieve is specially designed for Industrial oxygen generator for PSA/VPSA system, which has good selectivity of N2/O2,excellent crush strength, loss on attraction and little dust.


FAQ:
Q1: What's the main difference between Oxygen Molecular Sieve JZ-OI?
A1: Under same working condition, the same quantity will produce different quantity of oxygen which means the output capacity of
oxygen is different. And that the output capacity of Oxygen for JZ-OIL is the biggest, JZ-OI9 is second, JZ-OI5 is the smallest.

Q2: Regarding each type of JZ-OI, what's type of oxygen generator is suitable for?
A2: JZ-OI9 & JZ-OIL are suitable for PSA Oxygen Generators, for VPSA system Oxygen Generators, you should choose JZ-OIL & JZ-OI5.

Q3: What's the difference between them about the costs?
A3: JZ-OIL is higher than others and the JZ-OI5 is the lowest.




JOOZEO Strength





Shanghai Jiuzhou Chemicals Co., Ltd. was established in 2002. The company has two production bases, which are a company integrating R&D, production and sales. The Shanghai production base is located in Jinshan Second Industrial Zone, covering an area of 21,000 square meters; The Wuxi production base is located in Wuxi Liandong U Valley. Company has many utility model patents such as "Alumina Manufacturing System and Manufacturing Process" and "Belt Dryer Air Intake and Exhaust System"




1、Quality control

3+ independent laboratory
7+ routine inspections
2 years retention management for checking
Passed ISO, TUV system certifications
2、Dynamic Data

Dynamic data monitoring
Accurate product ratio
Complete plan development
Remote auxiliary debugging


3、Program Recommendation
20+years manafacturer ablity
15+years export experience
Cooperation with 60+ countries
Years of application experience
4、Supporting Services
Pre-sales: Help you find most suitableproduct with different application
In-sales: ERP system used to make product traceable.samples reserved for 2+ yearsincase anydispute
After-sales: Response within 24 hours for any problem




Q1: What's your production capacity?
A1: We can make 3,000 ton one month. If you have order plan, feel free to contact me, I will tell you delivery time according to your demand.
Q2: Do you have a catalogue? Can you send me the catalog to check all your products?
A2: Yes, We have product catalogue. Please contact us for catalog.
Q3: How can we guarantee quality?
A3: Always a pre-production sample before mass production;Always final Inspection before  shipment;
Q4: What about your delivery time?
A4: The delivery time should contract us and our salemen will tell you the delivery time
Q5: Why should you buy from us not from other suppliers?
A5: We have 20 years of professional experience in the production of Molecular sieve and other catalyst or absorbent, solid foundation, rich experience, with a complete and scientific quality management system.
