Заводская Oem материнская плата для мобильного телефона Pcba мини проектор от производителя
Заводская Oem материнская плата для мобильного телефона Pcba мини-проектор от производителя
Заводская Oem материнская плата для мобильного телефона Pcba мини-проектор от производителя
Заводская Oem материнская плата для мобильного телефона Pcba мини-проектор от производителя
Заводская Oem материнская плата для мобильного телефона Pcba мини-проектор от производителя
Заводская Oem материнская плата для мобильного телефона Pcba мини-проектор от производителя
Заводская Oem материнская плата для мобильного телефона Pcba мини-проектор от производителя

Заводская Oem материнская плата для мобильного телефона Pcba мини проектор от производителя

Share on:


Price:0,90 $ - 4,90 $
Price in USD:Details

Quantity:


Product Overview

Description





Product Paramenters


Factory Oem Motherboard Mobile Phone Pcba Mini Projector Board Manufacturing Supplier Make Custom Pcb


PCB Techinecal Capacity


Layers
Mass production: 2~58 layers / Pilot run: 64 layers
Max. Thickness
Mass production: 394mil (10mm) / Pilot run: 17.5mm
Material
FR-4 (Standard FR4, Mid-Tg FR4,Hi-Tg FR4, Lead free assembly material) , Halogen-Free, Ceramic filled , Teflon, Polyimide, BT,PPO, PPE, Hybrid, Partial hybrid, etc.
Min. Width/Spacing
Inner layer: 3mil/3mil (HOZ), Outer layer: 4mil/4mil(1OZ)
Max. Copper Thickness
UL certificated: 6.0 OZ / Pilot run: 12OZ
Min. Hole Size
Mechanical drill: 8mil(0.2mm) Laser drill: 3mil(0.075mm)
Max. Panel Size
1150mm × 560mm
Aspect Ratio
18:1
Surface Finish
HASL,Immersion Gold, Immersion Tin, OSP, ENIG + OSP, Immersion Silver, ENEPIG, Gold Finger
Special Process
Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and
Resistance control


PCBA technical Capacity







SMT
Position accuracy:20 um
Components size:0.4×0.2mm(01005) —130×79mm,Flip-CHIP,QFP,BGA,POP
Max. component height::25mm
Max. PCB size:680×500mm
Min. PCB size:no limited
PCB thickness:0.3 to 6mm
PCB weight:3KG


Wave-Solder
Max. PCB width:450mm
Min. PCB width: no limited
Component height:Top 120mm/Bot 15mm


Sweat-Solder
Metal type :part, whole, inlay, sidestep
Metal material:Copper , Aluminum
Surface Finish:plating Au, plating sliver , plating Sn


Press-fit
Air bladder rate:less than 20%
Press range:0-50KN
Max. PCB size:800X600mm
 Testing
ICT,Probe flying,burn-in,function test,temperature cycling




Products Description
















Hot Selling




Company Profile
















Exhibition




Our Advantages




Why Choose Us






FAQ


Q1:What service do you have?
IBE: We provide turnkey solution including RD, PCB fabrication, SMT, plastic injection & metal, final assembly,testing and other value-added service.

Q2:What are the main products of your PCB/PCBA services?
IBE: Our PCB/PCBA services are mainly for the industries including Medical, Automotive, Energy, Metering/Measurements, Consumer Electronics.

Q3:Is IBE a factory or trade company?
IBE: IBE is a factory with PCB factory located in China and SMT assembly factories in both China & USA.

Q4:Can we inspect quality during production?
IBE: Yes, we are open and transparent on each production process with nothing to hide. We welcome customer inspect our production process and check in house.

Q5:How can we ensure our information should not let third party to see our design?
IBE: We are willing to sign NDA effect by customer side local law and promising to keep customers data in high confidential level.

Q6:Do you have any minimum order quantity (MOQ) requirement?
IBE: No, we do not have MOQ requirement, we can support your projects starting from prototypes to mass productions.

Tell us your requirement about the FAQ by CLICKING HERE, so that we can provide solution to save your budget and meet your need!
