E104 BT05 blue tooth low energy module BLE 4.2 TLSR8266 wireless transmitter receiver ble4.2 blue tooth nrf52840 module
- Category: >>>
- Supplier: Chengdu Coogex Electronic Technology Co. Ltd.
Share on (1600734744389):
Product Overview
Description
Product Description
Specification
Main Para.Name | Min. | Max. | Remark. |
Input Voltage(V) | 0 | 3.6 | Permanent damage occurred when voltage is over 3.6V |
Blocking Power(dBm) | - | 10 | Low chance to be damaged for short-distance transceiving |
Working Temp.(℃) | 0°C | 85 | - |
Main Para.Name | Min. | Typ. | Max. | Unit |
Working Voltage(V) | 3 | 3.3 | 3.6 | Voltage above 3.3V can guaranty Max TX power |
Tx Electrical Level(V) | - | 3.3 | - | 5V TTL could cause permanent damage |
Working Temp(℃) | 0℃ | - | +70℃ | - |
Working FrequencyChannel(MHz) | 2402 | - | 2480 | Support ISM Chanel |
TX Current(mA) | 18.5 | - | 72.6 | - |
RX Current(mA) | 18.7 | - | 69.1 | - |
Max TX Power(dBm) | - | 3 | - | - |
RX Sensitivity(dBm) | - | -89 | - | - |
Arbitrary IO(VIL/VIH) | -/1.75V | - | 1.5V/- | - |
Arbitrary IO(VOL/VOH) | -/VCC-0.25 | - | GNG+0.25/- | - |
Connection Current(slave module) | - | 20 | - | mA |
Parameters | Value | Remarks |
Reference Range | 1500m@SUB-1GHz | Conditions: Clear Sky, Antenna Gain 5dBi, Antenna Height 2.5m, Air rate 1kbps |
Reference Range | 120m@2.4G | Conditions: Clear Sky, Antenna Gain 5dBi, Antenna Height 2.5m, Air rate 1Mbps |
TCXO Frequency | 48MHz/32.768k | High rate at 48MHz/Low Rate at 32.768k |
Protocol | GFSK | / |
Encapsulation | SMD | / |
Interface Type | 1.27mm Stamp Hole | / |
IC Model | CC1352P1F3RGZ | / |
FLASH | 352KB | / |
RAM | 80KB | / |
Core | Arm 庐 Cortex 庐 -M4F | / |
Size | 32*20mm | / |
Antenna Interfaces | IPEX/Stamp Hole@sub-1G, | |
PCB Antenna@2.4G | Equivalent Impedance is around 50惟 | |
Reference distance | 50m | Clear and open environment, antenna height 2.5m |
Launch length | 300Byte | - |
Bluetooth protocol | Bluetooth Specification V2.1+EDR | - |
Communication Interface | UART | |
Packaging type | SMD | - |
Interface method | 1.27mm | - |
Dimensions | 13*25mm | - |
product weight | 1.2卤0.1g | - |
Antenna interface | PCB Antenna | Equivalent impedance about 50惟 |
