Injection Moldable Grade Noryl GTX GTX810 10% Glass Reinforced PPE PA Alloy PPO Resin
- Category: >>>
- Supplier: Shenzhen Samtion Chemical Co. Ltd.
Share on (1600736636519):
Product Overview
Description
Products Description
NoryL 810
NORYL GTX810 resin is a 10% glass fiber reinforced alloy of Polyphenylene Ether (PPE) + Polyamide (PA). This injection moldable
grade has high stiffness (flexural modulus 3000 MPa), excellent chemical resistance, and high heat resistance.
grade has high stiffness (flexural modulus 3000 MPa), excellent chemical resistance, and high heat resistance.
Related Model:GTX 910/820/830
"NORYL" for the queen Mary innovation development by oxidation of xylene resin, plastic company in PPO for basic, one of aromatic polyether, the excellent material, through 17 kinds of feature combination, more conducive to injection molding, blow molding,extrusion, vacuum forming, to meet the industry needs lightweight, high security and more durable product requirements. Because of its excellent fire resistance, heat resistance, mechanical strength, electrical characteristics and dimensional stability, coupled with low water absorption and easy processing, it is widely used in water treatment equipment, computers, transaction machines,electronic parts, household appliances, communication equipment, water transportation parts and automobiles and other industries.
Product Paramenters
MECHANICAL | Value | Unit | Standard |
Nominal Stress, yld, Type I, 5 mm/min | 89 | MPa | ASTM D 638 |
Nominal Stress, brk, Type I, 5 mm/min | 88 | MPa | ASTM D 638 |
Nominal Strain, brk, 5 mm/min | 10 | % | ASTM D 638 |
Flexural Stress, yld, 2.6 mm/min, 100 mm span | 155 | MPa | ASTM D 790 |
Flexural Modulus, 2.6 mm/min, 100 mm span | 3960 | MPa | ASTM D 790 |
Hardness, Rockwell R | 119 | - | ASTM D 785 |
IMPACT | Value | Unit | Standard |
Izod Impact, notched, 23°C | 80 | J/m | ASTM D 256 |
Izod Impact, notched, -30°C | 53 | J/m | ASTM D 256 |
THERMAL | Value | Unit | Standard |
Vicat Softening Temp, Rate B/50 | 240 | °C | ASTM D 1525 |
HDT, 0.45 MPa, 6.4 mm, unannealed | 245 | °C | ASTM D 648 |
HDT, 1.82 MPa, 6.4 mm, unannealed | 210 | °C | ASTM D 648 |
CTE, -20°C to 150°C, flow | 3.96E-05 - 5.04E-05 | 1/°C | ASTM E 831 |
Relative Temp Index, Elec | 50 | °C | UL 746B |
Relative Temp Index, Mech w/impact | 50 | °C | UL 746B |
Relative Temp Index, Mech w/o impact | 50 | °C | UL 746B |
PHYSICAL | Value | Unit | Standard |
Specific Gravity | 1.16 | - | ASTM D 792 |
Density | 1.162 | g/cm³ | ASTM D 792 |
Water Absorption, 50% RH, equilib | 1 | % | ASTM D 570 |
Moisture Absorption, 50% RH, 24 hrs | 0.5 | % | ASTM D 570 |
Mold Shrinkage, flow, 3.2 mm | 0.6 - 0.8 | % | |
Mold Shrinkage, xflow, 3.2 mm | 0.65 - 0.85 | % | |
ELECTRICAL | Value | Unit | Standard |
Arc Resistance, Tungsten {PLC} | 6 | PLC Code | ASTM D 495 |
Hot Wire Ignition {PLC) | 0 | PLC Code | UL 746A |
High Voltage Arc Track Rate {PLC} | 3 | PLC Code | UL 746A |
High Ampere Arc Ign, surface {PLC} | 0 | PLC Code | UL 746A |
Comparative Tracking Index (UL) {PLC} | 3 | PLC Code | UL 746A |
FLAME CHARACTERISTICS | Value | Unit | Standard |
UL Recognized, 94HB Flame Class Rating (3) | 1.47 | mm | UL 94 |
CSA (See File for complete listing) | LS88480 | File No. | CSA LISTED |
High Voltage Arc Track Rate {PLC} | 4 | PLC Code | UL 746A |
High Ampere Arc Ign, surface {PLC} | 0 | PLC Code | UL 746A |
Comparative Tracking Index (UL) {PLC} | 1 | PLC Code | UL 746A |
FLAME CHARACTERISTICS | Value | Unit | Standard |
UL Recognized, 94HB Flame Class Rating (3) | 1.49 | mm | UL 94 |
