Product Description.
Hong jin Programmable 2 Zone Temperature Heat Cold Impact Testing Machine Battery Thermal Shock Test Chamber is divided into three boxes of cold and heat impact test box, two boxes of cold and heat impact test box, it is mainly used in
metal, plastic, electronic batteries, headphones, mobile phones, rubber, LED, home appliances, scientific research, colleges and universities and other material industry testing equipment.


Product Paramenters


Model number
TS-60(A-C)
 TS-80(A-C)
TS-150(A-C)
TS-252(A-C)
TS-450(A-C)
Internal Size WxHxD (cm)
50*40*30
50*40*40
60*50*50
70*60*60
80*75*75
External Size WxHxD (cm)
145*180*145
148*190*155
160*200*175
175*210*187
190*220*200
Temperature range (test area)
*150℃ A: -45° C; в:- 55° C; C: -65C; High temperature: + 60 C + 150 °C; Low temperature zone-10 ℃-65 ℃.
Heating time (heat storage area)
It takes about 35min at RT200℃
Cooling time(storage area)
It takes about 85min at RT-70℃
Temperature recovery time/conversion
≤within 5 min/≤within 10 seconds
Temperature control accuracy / distribution accuracy
±0.5℃/±2.0℃
Insulation material
High temperature high density chlorine formic acid b vinegar foam insulation material
system
P.I.D+s. s. R+balance of microcomputer temperature control system
Cooling system
Half closed double period of compressor (water-cooled)/full closed double period of compressor (air-cooled)
Safety protection device
No fuse switch, compressor high and low voltage protection switch, refrigerant high-pressure protection switch, failure warning system, electronic alarms
accessories
View window (special) of choose and buy, adjustable up and down layer of two pieces of insulation, electricity test hole, castor, horizontal support
Power supply
AC380V 50 hz /60 hz∮
Weight (approximate)
700KG
900KG
1200KG
1400KG
1900KG
