wholesale 5v dc axial cooling fan 40x40x10 brushless fan 40mm
- Category: >>>
- Supplier: Shenzhen Cooling Technology Co. Ltd.
Share on (1600738853575):
Product Overview
Description
wholesale 5v dc axial cooling fan 40x40x10 brushless fan 40mm
Product Description
DC Axial Fans
40x40x10mm
| Model | CLD4010 |  |
| Product Name | dc axial fans | |
| Size | 40x40x10mm | |
| Voltage Range | 5v 12v 24V | |
| Rated Current | 0.06Amp | |
| Power | 0.6W | |
| Speed | 4500~8500RPM | |
| Noise | 26dB-A | |
| Bearing | Sleeve/Ball Bearing | |
| Material | Plastic |
Specification
| Model | Voltage | Current | Power | Speed | Air Flow | Air Pressure | Noise |
| Part No. | VDC | Amp | Watt | RPM | CFM | mmH2O | dB-A |
| CLD4010L05 | 5 | 0.07 | 0.36 | 4500 | 3.93 | 2.09 | 24.6 |
| CLD4010LV05 | 5 | 0.10 | 0.48 | 5000 | 4.51 | 2.65 | 28.5 |
| CLD4010LM05 | 5 | 0.12 | 0.60 | 5500 | 4.83 | 3.03 | 30.0 |
| CLD4010M05 | 5 | 0.14 | 0.72 | 6000 | 5.16 | 3.43 | 31.0 |
| CLD4010ML05 | 5 | 0.17 | 0.84 | 6500 | 5.35 | 3.81 | 33.4 |
| CLD4010H05 | 5 | 0.19 | 0.96 | 7000 | 5.84 | 4.19 | 35.3 |
| CLD4010HL05 | 5 | 0.22 | 1.08 | 7500 | 6.30 | 4.72 | 37.1 |
| CLD4010HH05 | 5 | 0.24 | 1.2 | 8000 | 6.51 | 5.26 | 38.0 |
| CLD4010VH05 | 5 | 0.26 | 1.32 | 8500 | 7.02 | 5.92 | 39.5 |
| CLD4010L12 | 12 | 0.03 | 0.36 | 4500 | 3.93 | 2.09 | 24.6 |
| CLD4010LV12 | 12 | 0.04 | 0.48 | 5000 | 4.51 | 2.65 | 28.5 |
| CLD4010LM12 | 12 | 0.05 | 0.60 | 5500 | 4.83 | 3.03 | 30.0 |
| CLD4010M12 | 12 | 0.06 | 0.72 | 6000 | 5.16 | 3.43 | 31.0 |
| CLD4010ML12 | 12 | 0.07 | 0.84 | 6500 | 5.35 | 3.81 | 33.4 |
| CLD4010H12 | 12 | 0.08 | 0.96 | 7000 | 5.84 | 4.19 | 35.3 |
| CLD4010HL12 | 12 | 0.09 | 1.08 | 7500 | 6.30 | 4.72 | 37.1 |
| CLD4010HH12 | 12 | 0.10 | 1.20 | 8000 | 6.51 | 5.26 | 38.0 |
| CLD4010VH12 | 12 | 0.11 | 1.32 | 8500 | 7.02 | 5.92 | 39.5 |
Product Showcase
Product Structure
