Infrared Method Water Vapor Permeability Analyzer W413 2.0
Application
W413 2.0 Infrared Water Vapor Transmission Rate Tester is a high-end precision packaging material testing instrument developed by Guangzhou Biaoji R&D team based on ASTM and GB standard requirements and market demand. It is used to test the water vapor transmission rate of samples under set temperature and humidity conditions. rate (amount). It is suitable for the water vapor transmission performance test of films, sheets, paper, packaging parts and various materials in the fields of food, medicine, medical equipment, daily chemicals, photovoltaic electronics, etc. Ideal configuration instrument for material barrier properties.

Standard
ASTM F1249, BS EN ISO 15106-2, JIS K7129, YBB 00092003




Specification


Technical Specifications
Item
Technical parameters
Test range
0.002~200 g/(m2·24h)（film and sheet）
Test precision
0.0001 g/(m2·24h)（film and sheet）
Temperature range
15~45℃（15~60℃ optional）
Temperature accuracy
±0.1℃
Humidity range
(5～90）%RH，100%RH
Humidity accuracy
±2%RH
Test area
50.24 cm2（with additional adapting piece and be small as 0.785 cm2 ）
Sample size
Φ100 mm
Sample thickness
≤3 mm
Number of test sample
3Pieces
Carrier gas
99.999% N2（user provide）
Carrier gas pressure
≥0.1 MPa
Carrier gas flow
5~100 mL/min
Pneumatic pressure
≥0.3 MPa
Gas supply port
1/8 inch metal pipe
Instrument size
700 mm×630 mm×400 mm
Weight
60 kg
Power
750 W
Power supply
AC 220 V，50 Hz (110V as requested)


Company Profile








We GBPI is a professional manufacturer focused on developing
and producing packaging material test instruments. Founded in 2002, the company has received IOS9001 certification and recognized as high-tech enterprise and software enterprise by national authority. We hold numerous technology patents and software certificates from the national authority, and gained awards for technological progress.


Certifications




Our Customers




Packing & Delivery




To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
