Xinhai Single cylinder Hydraulic Cone Crusher Secondary Stone Crusher Machine Sand Making Machine
- Category: Mining Machinery >>>
- Supplier: Jiaozuo City Xinhai Mine Machinery Equipment Plant(General Partnership)
Share on (1600740520140):
Product Overview
Description
Product Description
DP Hydraulic Cone Crusher description:
DP Hydraulic Cone Crusher is widely used in mining, metallurgy, construction, highway, railroad, and water conservancy, etc. It can break or crush all kinds of medium hard or harder ore for mining, chemical building, materials and other industrial sectors. This kind of machine has the features of big crushing ratio, continuous operating, even granularity, automated hydraulic clearing system, high capacity, simple structure and low operating cost, suited perfectly for middle and fine crushing.
Product Features
DP Hydraulic Cone Crusher features:
1, Good grain shape and high efficiency
2, Strong crushing capacity
3, Run continuously and stably
4, Just replacing the fixed cone can achieve a variety of cavity shapes for fine crushing.
5, Adopt direct meta-contacting method, which facilitates replacing liner plates of mobile cone
and stationary cone
6, Double insurance controlled hydraulic and lubrication system can ensure the machine's
overload protection and good bearing lubrication.
7, Easy maintenance: The structure of cone crusher is simple and compact. It has the features of stable performance, not easy to fault and convenient maintenance.
Specifications
DP Hydraulic Cone Crusher specifications:
| Model | DP-100 | DP-160 | DP-250 | DP-300 | |
| Motor power(kw) | 75-90 | 110-160 | 132-250 | 200-315 | |
| Stroke(mm) | 16,20,25 | 18,25,32,40 | 18,25,32,40 | 18,25,32,40 | |
| Weight (T) | 9.8 | 12.8 | 23.2 | 38.5 | |
| Max feeding size(mm) | Medium Coarse Extra coarse | 200 250 | 250 330 | 280 380 | 380 500 |
Capacity of middle crushing
| DP-100S CAPACITY (t/h) | ||||||||||||
Discharging Stroke (mm) | 20 | 25 | 30 | 35 | 40 | 45 | ||||||
| 16 | 80-90 | 105-115 | 120-130 | 135-145 | 145-165 | 155-175 | ||||||
| 20 | 120-130 | 145-155 | 160-180 | 170-200 | 185-215 | |||||||
| 25 | 185-195 | 200-220 | 210-230 | |||||||||
| DP-160S (t/h) | ||||||||||||
Discharging Stroke(mm) | 20 | 25 | 30 | 35 | 40 | 45 | 50 | |||||
| 18 | 110-140 | 140-170 | 160-190 | 180-210 | 200-230 | 230-260 | ||||||
| 25 | 170-220 | 190-240 | 210-260 | 230-280 | ||||||||
| 32 | 230-280 | 270-320 | 280-350 | |||||||||
| DP-250S (t/h) | |||||||
Discharging Stroke(mm) | 20 | 25 | 30 | 35 | 40 | 45 | 50 |
| 18 | 170-190 | 170-210 | 190-230 | 210-255 | 235-275 | 255-295 | |
| 25 | 220-270 | 255-315 | 290-345 | 320-350 | 330-350 | ||
| 32 | 360-400 | 380-420 | 400-420 | ||||
| 40 | 450-500 | 480-530 | |||||
| DP-300S (t/h) | ||||||||
Discharging Stroke(mm) | 45 | 50 | 55 | 60 | 65 | 70 | 75 | 80 |
| 18 | 300-350 | 325-375 | 375-425 | 400-450 | 425-475 | 450-500 | 500-550 | 550-600 |
| 25 | 500-550 | 550-600 | 600-650 | 650-700 | 700-750 | 750-800 | ||
| 32 | 650-700 | 700-750 | 750-800 | 825-875 | 900-950 | 950-1000 | ||
