SIZE | engine | ||||||||
1 | Dimensions (mm) | 6150*2350*3763 | 1 | model | Yudong 4105 supercharged | ||||
2 | Wheelbase (nini) | 2200 | 2 | Type | turbo | ||||
3 | Wheelbase (nini) | 1850/2000 | 3 | Rated power (KW) | 85 | ||||
4 | Minimum ground clearance (mm) | 300 | 4 | Rated speed (r/min) | 2400 | ||||
5 | Minimum turning radius (mm) | 6580 | 5 | Number of cylinders - inner diameter | 4-105 | ||||
Performance parameters | Transmission system | ||||||||
1 | System pressure (Mpa) | 28 | 1 | gearbox | Fixed shaft power shift | ||||
2 | Machine weight (kg) | 8320 | 2 | Number of gears | before 2 after 2 | ||||
3 | Maximum speed (Km/h) | 22/38 | 3 | torque converter | YJ280 | ||||
4 | Maximum gradeability (°) | 35 | |||||||
Mining parameters | bridge | ||||||||
1 | Maximum telescopic digging depth (mn) | 4000/5500 | 1 | Type | A wheel side reduction axle | ||||
2 | Excavation unloading height (mm) | 4500/5500 | tire | ||||||
3 | Maximum excavation radius (mm) | 5800/7100 | 1 | Specification | 14-17. 5/19. 5L-24 | ||||
4 | Maximum lift height (mm) | 6060/7200 | 2 | service brake | Air-cap oil caliper disc brake | ||||
5 | Bucket Capacity (m3) | 0.3 | 3 | Parking brake | handbrake | ||||
6 | Excavator rotation angle (°) | 190 | oil quantity | ||||||
Load parameters | 1 | Fuel tank (L) | 100 | ||||||
1 | Maximum unloading height (mm) | 2742 | 2 | Hydraulic tank (L) | 100 | ||||
2 | Maximum unloading distance (mm) | 1062 | other | ||||||
3 | Bucket capacity (m3) | 1 | 1 | Transmission type | hydraulic shifting | ||||
4 | Rated load (KG) | 2500 | 2 | control system | Electromagnetic hydraulic pilot control | ||||
