FC155FP Dual fiber Single/Multi Mode optical media converter to Rj45 with SFP ethernet converter media converter
- Category: >>>
- Supplier: HiOSO Technology Co. Ltd.
Share on (1600740767417):
Product Overview
Description
overview
HiOSO FC155F series ATM single/multimode converters are suitable for 155Mbps ATM, SDH and 100Mbps Fast Ethernet for mixed
single-mode and multimode fiber cabling. It can realize mutual conversion between single-mode and multi-mode 1310nm wavelengths,
and mutual conversion between 850nm, 1310nm and 1550nm wavelengths, and realize signal aggregation, so that the transmission
distance of signals in multi-mode optical fibers can be extended. FC155F supports transmission in dual-fiber multimode, dual-fiber
single-mode and single-fiber single-mode fibers.
single-mode and multimode fiber cabling. It can realize mutual conversion between single-mode and multi-mode 1310nm wavelengths,
and mutual conversion between 850nm, 1310nm and 1550nm wavelengths, and realize signal aggregation, so that the transmission
distance of signals in multi-mode optical fibers can be extended. FC155F supports transmission in dual-fiber multimode, dual-fiber
single-mode and single-fiber single-mode fibers.
Feature
Supported protocols: 155Mbps ATM/SDH, IEEE802.3u 100BASE-FX and FDDI Support full-duplex and half-duplex network communication; It
can realize mutual conversion between 850nm/1310 multi-mode fiber and 1310nm/1550nm single-mode fiber; Support direct transparent
transmission of packets of different lengths; Low power consumption, low heat generation, stable operation for a long time;
Support dual-fiber multi-mode, dual-fiber single-mode, single-fiber single-mode and other types of optical fiber ports to meet
user expansion needs.
can realize mutual conversion between 850nm/1310 multi-mode fiber and 1310nm/1550nm single-mode fiber; Support direct transparent
transmission of packets of different lengths; Low power consumption, low heat generation, stable operation for a long time;
Support dual-fiber multi-mode, dual-fiber single-mode, single-fiber single-mode and other types of optical fiber ports to meet
user expansion needs.
Product Description
Specification
item | value |
Model Number | FC155FP |
Type | Fiber optic media converter |
Place of Origin | guangdong |
Brand Name | HiOSO |
Use | FTTX |
Warranty Time | 3 year |
Access mode | 155Mbps (100Mbps) |
Wavelength | 850nm/1310nm/1490nm/1550nm |
Conversion mode | Medium conversion |
Delay | <1μs |
Bit error rate | <1/1000000000 |
MTBF | 100,000 hours |
Power | AC220V 0.3A/DC-48V 0.5A |
Power consumption | 3.5W |
Standard | 155Mbps ATM/SDH, IEEE802.3u 100Base-FX Fast Ethernet, FDDI |
Transmission distance | Dual-fiber multi-mode: 2Km; Dual-fiber single-mode: 25/40/60/80/100/120Km |
Port | One multi-mode fiber port: Multi-mode-SC (fiber size: 50,62.5/125μm) One single-mode fiber port: single-mode- SC fiber port (fiber size: 9/125μm) |
LED | PWR (power) SM LINK (single-mode fiber link) MM LINK (multi-mode fiber link) |
Operating temperature | -10~55°C |
Operating humidity | 5%~90% |
Storage temperature | -40~70°C |
Storage humidity | 5%~90% (non-condensing) |
