Product Overview


Products Description

Who we are

JUNHUA® PEEK was founded in 2007, the initial business is PEEK precision parts. In 2013, JUNHUA® PEEK became the first company in China to realize PEEK stock shape massive extrusion. In 2020, the operation of Shandong Junhao ( subsidiary company of JUNHUA® PEEK for PEEK raw material polymerization) marks that JUNHUA® PEEK has fulfilled the full industrial chain of PEEK material.


Global Partner

Junhua ChinaPEEK is an innovative provider of PEEK polymer solution.Since 2007,this company has been providing PEEK raw material,PEEK rod,PEEK sheet,PEEK tube and PEEK parts to over 10,000 customers from over 40 countries around the world. These clients are manufacturing leader from different industries.

Analytical Instruments Industry
Food Processing and Filling Machinery Industry
Electronics Semiconductor Industry
Medical Device Industry
Automotive Industry
Petrochemical Machinery Industry
Textile Machinery Industry
Aerospace, Military Industryratio


RFQ about PEEK material
Question 1. What is PEEK ?

PEEK(Poly ether ether ketone) is the most well known and important member of the PAEK(Poly aryl ether ketone) group. This high-performance polymer material combines high-termperature resistance,good wear, and excellent mechanical properties.
For instance, the glass transition temperature of PEEK is around 143 °C (289 °F) ,and melts around 343 °C (662 °F). The carbon fiber filled PEEK or glass fiber PEEK material have a useful operating temperature of up to 250 °C (482 °F).
PEEK material is the best comprehensive performance of special engineering plastics. PEEK shows excellent overall performance due to its large amount of benezene ring structure in its molecule. At present, PEEK material made by Junhua PEEK is widely used in petroleum, food processing,semiconductor, texitile machinery,automotive,medical device,and aerospace industries.

Question 2. Which type of PEEK material is better for my product designing ?
I. PEEK5600G(unfilled PEEK or natural PEEK) advantage
PEEK5600G is one of unfilled or natural PEEK.It is a high performance, high temperature, semi crystalline thermoplastic material manufactured by JUNHUA PEEK. Outstanding chemical resistance and a high operating temperature (up to 250℃/480F) round out PEEK profile.PEEK plastic has excellent dimensional stability combined with high creep stability, ensuring the suitability of PEEK for the most sophisticated machined parts.
Besides, the unfilled black PEEK or black PEEK is also available.

II. PEEK5600CF30(30% carbon fiber filled PEEK ) advantage
PEEK5600CF30 is a 30% carbon filled PEEK material that is manufactured by JUNHUA PEEK. Its carbon fiber reinforcement supports the material a high level of rigidity. Carbon fiber reinforced PEEK demonstrates very high mechanical strength values.However,30% carbon fiber reinforced PEEK(PEEK5600CF30,1.4±0.02g/cm3)presents lower density than 30% glass fiber filled peek(PEEK5600GF30,1.5±0.02g/cm3).Besides,carbon fiber composites tend to be less abrasive than glass fibers while simultaneously resulting in improved wear and friction properties. The addition of carbon fibers also ensures a significantly higher level of heat conductivity which is also beneficial for increasing part life in sliding applications. Carbon filled PEEK has also an excellent resistance to hydrolysis in boiling water and super heated steam.

III. PEEK5600GF30( 30% glass fiber filled PEEK) advantage
Compared with unfilled PEEK(PEEK5600G),this 30% glass fiber reinforced PEEK material(PEEK5600GF30) exhibits increased mechanical strength and high rigidity.Plus, improved creep strength and dimensional stability are delivered by the 30% glass fiber filled PEEK. These properties make this material suitable for use in parts which are exposed to high static loads over long periods in high temperature conditions.PEEK5600GF30 is widely used in the buyer cases, which has a marked compressive strength requirement on the product designing.

IV. PEEK5600LF30( HPV PEEK or bearing grade PEEK) advantage
PEEK5600LF30 black is developed especially for bearing and sliding applications. HPV PEEK is based on a PEEK polymer that has been modified with 10% each of PTFE, graphite and carbon fibres. It combines the properties of a high-grade matrix material with special, wear-improving additives. Compared to PEEK modifications(like PEEK5600GF30,PEEK5600CF30),PEEK5600LF30 black has the lowest coefficient of friction, and shows higher wear resistance. Furthermore, a comparatively higher dimensional stability under thermal load is delivered.

V. Can do you manufacture the customized PEEK?
Yes, we make the customized size or shape of PEEK products.Like irregular PEEK plate, PEEK tube made by JUNHUA PEEK, in order to meet the buyer`s new product requiremnet on less PEEK material cost.
In addition, different color of PEEK material we make to meet the buyer`s new project demand. Different polymer material filed to add the speical performance of PEEK product, and the like.

VI. Do you make the OEM / ODM PEEK materials or PEEK products ?
Yes, JUNHUA PEEK provides the suggestions for material selection,cost accounting, product design, process selection, mold design and manufacturing to help you complete the product quick design, manufacturing and procurement process. You tell us your PEEK product designing requirement, we provide you the One-stop PEEK solutions service.

Question 3. Why JUNHUA PEEK ?
JUNHUA PEEK is the premier PEEK product manufacture in China.This manufacture is a one-stop PEEK production solution partner for worldwide buyers.

I. Junhua Company Profile
Company name : Junhua PEEK
Established date : 15th Nov 2007
Factory location(1) : Changzhou, Jiangsu
Factory location(2) : Jining, Shandong
NO. of employees : 398
Business range : focus on high-performance special engineering plastics PEEK,PI and PPSU products and their related application R&D and production of resins, profiles and parts
Business philosophy: integrity, pragmatism, cooperation, innovation, win-win
Business vision : delicated to being an innovative leader in the high performance PEEK polymer solutions

II. Junhua PEEK Development History
2003 Thermoplastic polyimide (PI) production
2007 Foundation of Junhua PEEK
2012 The first China maker of 2-meter-long PEEK sheet by mould compression process
2012 The first enterprise standard for PEEK rod,PEEK sheet, PEEK tube in China
2013 The first company to R&D the continuous extruded PEEK round bar,PEEK plate, PEEK hollow bar.
2014 High-tech product certification of Jiangsu Province as the leading PEEK manufacture
2015 National high-tech enterprise certification as the premier PEEK factory of PEEK rod,PEEK sheet and PEEK tubing
2016 PEEK cable extrusion
2017 2 Tons of PEEK plate and PEEK bar, PEEK profiles exported to Germany.
2018 2,500-ton PEEK polymer material factory in Jining, Shandong
2018 The first China manufacture of CF/PEEK thermoplastic composite,which is used in the aerospace industry and medical industry mainly.
2019 A wholly-owned subsidiary, Changzhou Junhua Medical Technology Co., Ltd,which focus on medical grade PEEK rod,sheet,tubing and biocompacibility PPSU rod,sheet,and other medical device related PEEK products.
2019 100,000-class clean workshop for PEEK capillary and PEEK medical products
2019 PEEK product for Changzheng 5B carrier rocket project
2020 Potential Qualified Supplier of COMAC(Commercial Aircraft Corporation of China, Ltd.), high-quality
2021 National standards for polyetheretherketone (PEEK) 2022 IPO plan

III. JUNHUA PEEK Quality Certificates
System Certifications: ISO900: 2015, IATF16949,GJB 9001C-2017, AS9100D
Product Certifications: Food Contact Material,RoHS,REACH
