Bioevopeak Lab Optical Instruments Portable Grating Spectrophotometer Color Spectrophotometer, SP CLR500C
- Category: >>>
- Supplier: Bioevopeak Co. Ltd.
Share on (1600741680722):
Product Overview
Description
Bioevopeak Lab Optical Instruments Portable Grating Spectrophotometer Color Spectrophotometer, SP-CLR500C
Features
Portable Grating Spectrophotometer has powerful performance configuration which makes color measurement more professional. Excellent inter-instrument error ensures consistency of the measurement data of multiple devices.
Features
- 20 kinds of color indexes and 26 kinds of illuminants
- Supports 26 kinds of illuminants such as D65/D50,etc.
- It can get the value of reflectance, CIE-Lab,CIE-LCh, whiteness, yellowness, opacity, color strength and other color indexes.
- Excellentinter-instrument error
Inter-instrument error
- Auto calibration
The auto calibration technology allows the instrument to achieve automatic calibration, which greatly improves the user experience.
- Multi-function calibration base
- The multi-function calibration base keeps the whiteboardbeing protected, combining calibration and charging functions in one.
- When instrument is placed on the base, it will be automatically charged and calibrated. It saves a lot of time for the user to charge and calibration the device.
Specifications
Model | SP-CLR500C |
Optical Geometry | D/8 (diffused illumination,8° viewing), SCI(specular component included) |
Integrating Sphere Size | φ40mm |
Light Source | Full waveband balanced LED |
Color Space and Index | Reflectance, CIE-Lab, CIE-LCh, HunterLab, CIE Luv, XYZ, Yxy, RGB, Color difference(ΔE*ab, ΔE*cmc, ΔE*94,ΔE*00),WI(ASTM E313-00,ASTM E313- 73,CIE/ISO, AATCC, Hunter, Taube Berger Stensby), YI(ASTM D1925,ASTM E313-00,ASTM E313-73), Blackness(My,dM),Color Fastness, Tint,(ASTM E313-00), Color Density CMYK(A,T,E,M), Milm, Munsell, Opacity, Color strength |
Illuminant | A,B,C,D50,D55,D65,D75,F1,F2,F3,F4,F5,F6,F7,F8,F9,F10,F11, F12,CWF,U30,U35,DLF,NBF,TL83,TL84 |
Observer Angle | 2°,10° |
Sensor | 256 pixel CMOS sensor |
Calibration | Auto |
Wavelength Interval | 10nm |
Wavelength Range | 400-700nm |
Measured Reflectance Range | 0-200% |
Reflectance Resolution | 0.01% |
Repeatability | Chromaticity value: Max. :dE*ab< 0.1 Average :dE*ab< 0.05 Standard deviation within ΔE*ab 0.03 (When a whiteboard measures 30 times every 5 seconds) Reflectance: Standard deviation < 0.1% |
Measuring Aperture | MAV: φ8mm/φ11mm |
Inter-instrument Error | ΔE*ab<0.3 (BCRA Series Ⅱ, average measurement of 12 tiles,MAV/SCI) |
Measuring Time | About 2s |
Battery | Rechargeable, 8000 times continuous tests, 3.7V/3000mAh |
Screen | 2.4-inch IPS full color screen |
Interface | USB,Bluetooth |
Illuminant Life Span | 1 million measurements in 10 years |
Software Support | Android, IOS, Windows |
Camera | Without |
External Dimension (L*W*H) | 77.8*53.2*185.7mm |
N.W./G.W. | 0.3kg/1.5kg |
Shipping Dimension (L*W*H) | 320*170*290mm |
Packaging & Shipping
Ceritificates
About us
FAQ
Q: How about quality of the goods?
A:
l All the running products comply with CE standards.
l Independent quality inspection team, conducting multiple inspections and random inspections from parts supply to product dispatch.
l Well-known third-party testing service available, such as SGS, BV, and TUV, etc.
Q: What are your pre- and after-sales services?
A:
l Timely reply to pre-sales enquiries
l Real-time update of manufacturing and shipment status
l Contracted third-party maintenance company in over 60 countries
Assured availability of parts supply for 10 years at least
Q: Is OEM service available.
A: Most of the running products are available for OEM customization, including logo, package and function, if attainable, customization.
Q: How long is the lead time:
A: Generally, the lead time for most stocked products is about 7~15 days, vary by models and production schedule. For those non-stocked products, the manufacturing lead time is around 20 days.
