Semi trailer Accessories12tons Bpw Axle 16t Axle Suitable For 2/3/4 Axle Mechanical Suspension
- Category: >>>
- Supplier: Liangshan Juxin Machinery Co. Ltd.
Share on (1600742853573):
Product Overview
Description
Product Description
1. High-end good material: Light duty type and heavy duty both have.
1. High-end good material: Light duty type and heavy duty both have.
2. Skilled and skilled: Perfect welding technology and painting technology
3. Standard size: Standard platform and bolt.
Model | Capacity (kg) | Brake size(mm) | Track (mm) | Axle Tube (mm) | Studs | PCD | Total length (mm) | Bearing |
FJX-12T | 12000 | S420*180 | 1840 | 150*150*12 | 10*M22*1.5 ISO | 335 | ~2144 | 32313/33118 |
FJX-14T | 14000 | S420*180 | 1840 | 150*150*14 | 10*M22*1.5 ISO | 335 | ~2198 | 32315/32319 |
FJX-16T | 16000 | S420*200 | 1850 | 150*150*16 | 10*M22*1.5 ISO | 335 | ~2272 | 32314/32222 |
Product Advantages
1.Specially processed one quality low alloy steel axle tube, which has strong bearing capacity, long service life, light weight
and excellent performance.
2, "P" type integral straight or tapered shaft head, bearing place adopts intermediate frequency quenching, strong anti fatigue
ability.
3, The high precision brake system makes the braking performance more stable.
4, "Q" type heavy brake, and equipped with powerful return spring.
5 .High performance asbestos free brake friction plate, good braking performance, long wear resistance and long service life.
6 .Camshaft with special seals, to ensure that grease does not enter the brake drum, to ensure safety.
7, The new sealed wheel hub with O sealing ring, good sealing performance.
8. XHP222 mobil oil extended maintenance free time.
1.Specially processed one quality low alloy steel axle tube, which has strong bearing capacity, long service life, light weight
and excellent performance.
2, "P" type integral straight or tapered shaft head, bearing place adopts intermediate frequency quenching, strong anti fatigue
ability.
3, The high precision brake system makes the braking performance more stable.
4, "Q" type heavy brake, and equipped with powerful return spring.
5 .High performance asbestos free brake friction plate, good braking performance, long wear resistance and long service life.
6 .Camshaft with special seals, to ensure that grease does not enter the brake drum, to ensure safety.
7, The new sealed wheel hub with O sealing ring, good sealing performance.
8. XHP222 mobil oil extended maintenance free time.
