Length x Width x Height | 2305×1100×1350 mm |
Wheelbase | 1460 mm |
Seat height | 530 mm |
Minimum Ground Clearance | 250 mm |
Minimum Turning Diameter | 850 mm |
Curb Weight | 370 kg |
Payload Capacity | 230 kg |
Fuel Capacity | 14 L |
Maximum Speed | 95 km/h |
Engine Type | Single-cylinder, Liquid cooled, 4-valve, SOHC, EFI |
Displacement | 495cc |
Bore X Stroke | 91 X 76.2 mm |
Maximum Power | 25.5 kW/6250 rpm |
Maximum Torque | 40 N·m/6000 rpm |
Fuel Supply | EFI |
Ignition | ECU |
Transmission | CVT |
Drive | Switchable 2WD/4WD |
Brake | Front wheel side brake + rear wheel axle brake |
Suspension Travel | Front/Rear: Double arm, independent suspension |
Rim | Front:12×6.0 AT Rear: 12×7.5 AT |
Tire Pressure | Front:AT 25×8.00-12 Rear: AT 25×10.00-12 |




Length(mm) | 2290 |
Width(mm) | 1450 |
Height(mm) | 860 |
G.W. (kg) | 440 |
N.W. (kg) | 397 |
Vol. (m³) | 2.56 |
40’HQ | 23 |
