Product Overview
Description
Wireless Standards | IEEE 802.11b/g/n |
Antenna Type | 2 External Antenna (IPEX/MHF 1) |
Voltage | 3.3V±5% |
33.2mm*18.7mm*3.0mmDimension(L×W×H) | Dimension(L×W×H) |
Frequency Range | 2.412GHz---2.484 GHz |
IEEE 802.11b : 1,2,5.5,11Mbps | |
IEEE 802.11g : 6,9,12,18,24,36,48,54Mbps | |
IEEE 802.11n : MCS0--MCS7 @ HT20 | |
MCS0--MCS7 @ HT40 | |
HT40 MCS7 : -70dBm@10% PER(MCS7) | |
HT20 MCS7 : -73dBm@10% PER(MCS7) | |
54M: -77dBm@10% PER | |
11M: -89dBm@ 8% PER | |
DSSS (DBPSK, DQPSK, CCK) | |
OFDM (BPSK, QPSK, 16-QAM, 64-QAM) | |
Wireless Security | WPA/WPA2, WEP, TKIP and AES, WPS2.0, WAPI |
Transmit Power | IEEE 802.11n: 16dBm @HT20/40 MCS7 |
IEEE 802.11g: 16dBm @54MHz | |
IEEE 802.11b: 18dBm @11MHz | |
Work Mode | IoT Gateway/IoT Device |
Environment | Operating Temperature: -20℃~55℃ |
Storage Temperature: -40℃~125℃ | |
Operating Humidity: 10%~90% non-condensing | |
Storage Humidity: 5%~90% non-condensing |
USB Dongle WiFi Module
◆IEEE 802.11a/b/g/n/ac WLANs
◆2.4G /5G ITIR mode
◆With support of 433Mbps PHY rate
◆IEEE 802.11e QoS Enhancement(WLAN)
◆USB LPM/Selective Suspend support
◆Fully compliance with USB2.0 High-speed mode.
◆IEEE 802.11i(WPA, WPA2). Open, shared key, and pair-wise key authentication services
◆2.4G /5G ITIR mode
◆With support of 433Mbps PHY rate
◆IEEE 802.11e QoS Enhancement(WLAN)
◆USB LPM/Selective Suspend support
◆Fully compliance with USB2.0 High-speed mode.
◆IEEE 802.11i(WPA, WPA2). Open, shared key, and pair-wise key authentication services
2.4G IoT Router WiFi Module
◆ Compliant to IEEE 802.11b/g/n.
◆ 1T1R 2.4GHz with support for a 150Mbps PHY data rate.
◆ 1T1R 2.4GHz with support for a 150Mbps PHY data rate.
◆ DDR2 memory up to 1024Mb.
◆ Flash memory up to 256Mb.
◆ 4 LAN ports and 1 WAN port.
◆ 24 STA-Proxy.
◆ Support interface: SD-XC, I2C, PCM, I2S(192K/24bits), PWM, SPI slave, UART lite, GPIO.
◆ Support IOT gateway mode and IOT device mode.
◆ Flash memory up to 256Mb.
◆ 4 LAN ports and 1 WAN port.
◆ 24 STA-Proxy.
◆ Support interface: SD-XC, I2C, PCM, I2S(192K/24bits), PWM, SPI slave, UART lite, GPIO.
◆ Support IOT gateway mode and IOT device mode.
Dual Band Router WiFi Module
◆ Compliant to IEEE 802.11b/g/n.
◆ 2T2R mode with support for a 300Mbps PHY data rate.
◆ 2T2R mode with support for a 300Mbps PHY data rate.
◆ DDR2 memory up to 1024Mb.
◆ Flash memory up to 256Mb.
◆ 4 LAN ports and 1 WAN port.
◆ Support USB 2.0 slave device for USB disk and USB 3G/4G dongle and USB camera.
◆ Support interface: I2C, PCM, I2S(192K/24bits), PWM, SPI slave, UART lite, GPIO,SD card
◆ Support AP/Client/Router mode.
◆ Flash memory up to 256Mb.
◆ 4 LAN ports and 1 WAN port.
◆ Support USB 2.0 slave device for USB disk and USB 3G/4G dongle and USB camera.
◆ Support interface: I2C, PCM, I2S(192K/24bits), PWM, SPI slave, UART lite, GPIO,SD card
◆ Support AP/Client/Router mode.
