original DSE 2133 DSENet RTD Thermocouple Input Expansion Module DSE2133 DC SUPPLY CONTINUOUS VOLTAGE RATING 8V to 35V
- Category: >>>
- Supplier: Fuan Shenzhou Electrical Co. Ltd.
Share on (1600747459000):
Product Overview
Description
Product Description
DSE2133 （no original box)
The DSE2133 is an RTD/thermocouple input expansion module providing 8 additional inputs to the control module. Up to 4 DSE2133
modules can be linked together to provide up to 32 additional inputs.
modules can be linked together to provide up to 32 additional inputs.
DC SUPPLY
CONTINUOUS VOLTAGE RATING
8V to 35V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved
without the need for internal batteries. LEDs
will not be maintained during cranking.
MAXIMUM OPERATING CURRENT
292 mA at 12 V, 167 mA at 24 V
MAXIMUM STANDBY CURRENT
101 mA at 12 V, 66 mA at 24 V
INPUT
8 inputs configurable as RTD/Thermocouple
CONTINUOUS VOLTAGE RATING
8V to 35V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V. This is achieved
without the need for internal batteries. LEDs
will not be maintained during cranking.
MAXIMUM OPERATING CURRENT
292 mA at 12 V, 167 mA at 24 V
MAXIMUM STANDBY CURRENT
101 mA at 12 V, 66 mA at 24 V
INPUT
8 inputs configurable as RTD/Thermocouple
Specification
Customizable | Yes | ||||||
Phase | Single-phase generator, single-phase/three-phase | ||||||
In stock | ≥ 500 | ||||||
Certificate | CE, RoHS, ISO9001 | ||||||
Warranty | 1 year / 12 months | ||||||
Hz | 50hz / 60hz | ||||||
