High Frequency PCB capabilities
Item
Capability
Quality Grade
Standard IPC 2
Number of layers
2-24layers
Order Quantity
1pc-10000+pcs
Build Time
2days-5weeks
Material
RO4003C, RO4350B, RT5880
PP
Rogers 4450F, Domestic-(25FR), Domestic-(RF-27), Domestic-(6700)
Board Size
Min 6mm x 6mm | Max 457mm x 610 mm
Board thickness
0.4mm -5.0mm
Copper weight
0.5oz - 2 oz
Min Tracing/spacing
3.5mil/3.5mil
Solder Mask color
Green, White, Blue, Red, Black, Yellow, Pink .etc
Silkscreen color
White, Black, Yellow, Green .etc
Surface finish
Electroless Nickel/Immersion Gold(ENIG)-RoHs
Immersion Silver - RoHs
Immersion Tin - RoHs
Organic solderability presercatives - RoHs
Min Annular Ring
4mil
Min Drilling Hole Diameter
6mil
Impedance tolerance
+/- 10%
Other Techniques
Peelable solde mask
Gold fingers
Carbon oil
Countersink holes






We manufacture high-frequency PCBs with frequency typically in the range from 500MHz to 2GHz. Common brand we use is Rogers Telfon and Taconic Telfon. Other customized brand is also acceptable. Sandwich buildups for material combinations are also possible.






Layer: 4 Layer
Material: Rogers + FR4 1/1oz TG170
Min trace width: 0.2mm
Min trace space: 0.2mm
Type: High Frequency PCB
Application: RF Testing Devices





Layer: 2 Layer

Material: Roger 4003C

Type: High Frequency PCB

Application: High frequency equipment










FAQ



 QUESTION1 Q:What are needed for quotation?
A: PCB: Quantity, Gerber file and Technical requirements(material,surface finish
treatment, copper thickness,board thickness . .
PCBA: PCB information, BOM, (Testing documents..)

QUESTION 2 Q:What file formats do you accept for production? ..
Gerber file: CAM350 RS274X
PCB file: Protel 99SE, P-CAD 2001 PCB
BOM: Excel (PDF,word,txt)

QUESTION 3 Q:Are my files safe?
Your files are held in complete safety and security.We protect the itellectual property
for our customers in the whole process.. All documents from customers are never
shared with any third parties.

QUESTION 4 Q:MOQ?
There is no MOQ in POE.We are able to handle small as well as large volume production
with flexibility.

QUESTION 5 Q:Shipping cost?
The shipping cost is determined by the destination, weight, packing size of the goods.
Please let us know if you need us to quote you the shipping cost.
