Chinese High precision metal product M 6016 Moving Gantry Type CNC Milling Drilling Tapping Machining Center With Fixed Table
- Category: >>>
- Supplier: Guangzhou Jasu Precision Machinery Co. Ltd.
Share on (1600750513053):
Product Overview
Description
Product Overview
3 axis double exchange linear guide rotary workbench machining center
Employ for European type design. Dismounting workpiece continuously by rotary double exchange worktable. work efficiency has been improved greatly
PRODUCT SPECIFICATIONS
Item | V-645Z | V-645S | V-850S | ||
worktable | table size | 600x500 | 800x550 | ||
2 | T-slot size | M12x100 | M16x120 | ||
3 | MAX.load capacity | 2x200kg | 2x300kg | ||
travel | MAX. X/Y/Zaxis travel | 600/450/350(500) | 800/500/500 | ||
5 | spindle nose to table surface | 150~500(150~650) | 100~600 | ||
6 | spindle center to column surface | 500 | 580 | ||
spindle | spindle taper | BT30(BT40) | BT40 | ||
MAX. spindle speed | 12000(8000)rpm | 8000rpm | |||
spindle drive | Belt drive(directly) | Belt drive | |||
feeding | cutting feedrate | 10000mm/min | 10000mm/min | ||
X/Y/Zaxis rapid traverse | 36/36/36m/min | 25/25/25m/min | |||
Ballscrew spec | 3216 | 4010 | |||
7 | positional accuracy | 0.01 | 0.01 | ||
8 | Repeated positioning accuracy | 0,.007 | 0.007 | ||
Servo motor | spindle motor | 5.5/7.5(7.5/11)kw | 7.5/11kw | ||
X/Y/Z axis servo motor(FANUC) | 1.8/1.8/1.8kw | 1.8/1.8/3.0kw | |||
coolant motor | 0.49kw | 0.49kw | |||
general | air requirement | 8KG | 8KG | ||
power capacity | 10KVA | 20KVA | |||
Measurement | 2.8x3.0x2.4m | 3.5x3.0x2.7m | |||
N.W | 3.5T | 4.0T | 5.8T | ||
A. T. C(optional) | ATC type | Arm type | disc type | disc type | |
ATC capacity | 16 | 24 | 24 | ||
MAX. tool diameter and length | 60x200 | 80x200 | 80x200 | ||
MAX. tool weight | 3kg | 7kg | 7kg | ||
Tool shank type | BT30 | BT40 | BT40 | ||
tool change time(T--T) | 1.2s | 2.8s | 2.8s | ||
PRODUCT CONFIGURATION
buffing machine
GSK controler
circular tool magazine
