FEP Material and ROHS Standard FEP Heat Shrink Tubing

Share on (1600751293593):


Price:

Quantity:


Product Overview

Description




FEP Material and ROHS Standard Teflon FEP Heat Shrink Tubing





The exceptional difference to FEP is that whilst the maximum continuous working temperature is 260°C, the shrinking temperature is only 110°C.


Used initially for UV lamps in electronic fly killers, and subsequently for white lights, FEP has proved to be the ultimate coating material for


shatterproofing lamps for this application.


It allows glass and mercury to be safely contained when breakage occurs, yet does not become degraded by the heat or UV emitted by the lamps.





FORBEST FEP safety coated shatterproof lamps are used where a glass free area is required:


·     Schools and Colleges


·     Public spaces


·     Hotels and Restaurants


·     Warehousing and storage


·     Food processing plants


·     Food preparation and display areas


·     Supermarkets


·     Bakeries


·     Pharmaceutical plants


·     Medical centres, Dentists and hospitals


·      Leisure centres and swimming pools


·      Agricultural Industry


·      Stables and Liveries



























































































































































  Spec(before shrink) in mm



Heat shrink rate



Spec ( After shrink) in mm



0.8



1.3:1



0.6



1.0



0.7



1.5



1.0



1.8



1.5



2.0



1.5



2.5



2.0



3.0



2.5



4.0



3.2



5.0



3.8



6.0



4.5



7.0



5.2



8.0



6.1



9.0



7.0



10.0



7.7



11.0



7.5



12.0



9.2



13.0



10



14.0



11



15.0



11.5



16.0



12.0



17.0



13



18.0



14



19.0



14.5



20.0



15



22.0



17



28.0



21.5



32.0



24.5



42.0



32



52.0



40



65.0



50.0



85.0



65



112.0



86
