CM10 SP10S M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors
CM10-SP10S-M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors
CM10-SP10S-M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors
CM10-SP10S-M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors
CM10-SP10S-M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors
CM10-SP10S-M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors

CM10 SP10S M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors

Share on (1600753687601):


Price:$2.90

Quantity:


Product Overview

Description





CM10-SP10S-M waterproof IP67 Encoder connector bayonet Metal Straight right angle DDK 10pin circular connectors








Product Information
Pin Front Insulator： Synthetic Rubber/Black
Pin Rear Insulator ：Plastic(UL94V-0)/Black
Pin Contact ： Copper Alloy/Gold Plating
O Ring(Mounting Side) ：Synthetic Rubber/Black
Receptacle Shell Zinc Alloy/Trivalent Chromium Finish(Black） Retaining Ring Copper Alloy/Nickel Plating Ground Lug Copper
Alloy/Gold Plating


Electrical Characteristic
Rated Voltage:200V AC(r.m.s.)

Rated Current:3A／Contact

Dielectric Withstanding Voltage: 1500V AC(r.m.s.)／１minute. [2-Contact] 900V AC(r.m.s.)／１minute. [10-Contact]

Insulation Resistance:1000MΩ min. at 500V DC
Environment
Operating Temperature:-25℃ to +85℃
