Product Overview
Description
HUASTLINK quectel EM16 EM160 EM160R EM160RGLAU-M21-SGADA LTE-A Cat16 4G m.2 wifi Wireless module EM160R-GL
Product Description
Quectel EM160 is an LTE Advanced category 16 module optimized specially for M2M and IoT applications. Adopting the
3GPP Rel-12 LTE technology, it delivers M2M-optimized speeds of 1000 Mbps downlink and 150 Mbps uplink peak data rates.
Designed in the M.2 form factor, EM160 is compatible with Quectel Cat 6 module EM06 , which will facilitate customers to
migrate between different categories.
EM160 is designed for global and nearly covers all the main stream carriers worldwide.
EM160, optionally, supports Qualcomm® IZat™ location technology Gen9HT Lite (GPS, GLONASS, BeiDou, Galileo). The
integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning
capability.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB drivers for Windows 7, Win
dows 8/8.1, Windows 10, Linux, Android/eCall, etc.) extend the applicability of the module to a wide range of M2M and IoT
applications such as industrial router, home gateway, STB, industrial laptop, consumer laptop, industrial PDA, rugged tablet
PC, video surveillance and digital signage, etc.
3GPP Rel-12 LTE technology, it delivers M2M-optimized speeds of 1000 Mbps downlink and 150 Mbps uplink peak data rates.
Designed in the M.2 form factor, EM160 is compatible with Quectel Cat 6 module EM06 , which will facilitate customers to
migrate between different categories.
EM160 is designed for global and nearly covers all the main stream carriers worldwide.
EM160, optionally, supports Qualcomm® IZat™ location technology Gen9HT Lite (GPS, GLONASS, BeiDou, Galileo). The
integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning
capability.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB drivers for Windows 7, Win
dows 8/8.1, Windows 10, Linux, Android/eCall, etc.) extend the applicability of the module to a wide range of M2M and IoT
applications such as industrial router, home gateway, STB, industrial laptop, consumer laptop, industrial PDA, rugged tablet
PC, video surveillance and digital signage, etc.
Model Number | EM160 | ||
UE-Category | LTE-A Cat16 module | ||
Dimensions | 51*30*4.9mm | ||
Form Factor(Package) | M.2 | ||
Frequency Bands | LTE-FDD | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29①/B30/B32①/B66 | |
LTE-TDD | B38/B39/B40/B41/B42/B43/B46① (LAA)/B48 (CBRS) | ||
WCDMA | B1/B2/B3/B4/B5/B6/B8/B19 | ||
GSM | / | ||
Supply Voltage | -35°C ~ +75°C | ||
Operation temperature | 3.0V~3.6V, 3.3V | ||
Embedded Software | Protocol | TCP/ UDP/ PPP/ FTP/ HTTP/ NTP/ PING/ QMI/NITZ/ CMUX/ HTTPS/ SMTP/ MMS*/ FTPS*/ SMTPS/ SSL/ FILE | |
Android RIL | Android 4.x/5.x/6.x/7.x/8.x/9.x | ||
USB Driver | Windows 7/8/8.1/10, Linux 2.6~5.4, Android 4.x/5.x/6.x/7.x/9.x | ||
MBIM Driver | Windows 8/ 8.1/ 10, Linux 3.8~5.4 | ||
Data Transmission | LTE | LTE-FDD: Max 1000Mbps (DL)/Max 150Mbps (UL) LTE-TDD: Max 430Mbps (DL)/Max 90Mbps (UL) | |
GPRS/EDGE | EDGE: Max 296Kbps (DL)/Max 236.8Kbps (UL) GPRS: Max 107Kbps (DL)/Max 85.6Kbps (UL) | ||
Firmware update | Via USB/DFOTA | ||
Interfaces | (U)SIM 1.8V/ 3.0VUART 1 USB 3.0 (Hi-Speed) IIC Antenna Pads for Primary, Rx-diversity and GNSS | ||
Embedded GNSS | GPS/GLONASS/BeiDou(Compass)/Galileo/QZSS (Optional) | ||
Region | Global | ||
LTE-A Cat 16 module with M.2 form factor, optimized for eMBB and
IoT applications
Support DL 3 × Carrier Aggregation and 256QAM
Worldwide LTE-A and UMTS/HSPA+ coverage
Multi-constellation GNSS receiver available for applications requiring
fast and accurate fixes in any environment
Feature refinements: supports DFOTA and VoLTE
MIMO technology meets demands for data rate and link reliability in
modem wireless communication systems
IoT applications
Support DL 3 × Carrier Aggregation and 256QAM
Worldwide LTE-A and UMTS/HSPA+ coverage
Multi-constellation GNSS receiver available for applications requiring
fast and accurate fixes in any environment
Feature refinements: supports DFOTA and VoLTE
MIMO technology meets demands for data rate and link reliability in
modem wireless communication systems
