--To adopt the gearbox and torque converter to provide a super power, walking stesdily and higher reliablity, high tansmission efficiency, long life.
--To combined excavator and loader as one machine, fully equipped with all function of mini excavator ad loader, more suitable for operating in a narrow space, convenient and flexible, reducing the whole purchase cost.
--Excavation and loading function are pilot control, light and high efficiency.
--Excavation slideslip device make the excavation operations broader and more efficient. For municipal, building, water conservancy, road, water, electricity, garden and other departments, engaged in agricultural, pipe laying, cable laying, landscaping and other jobs.
| Main performance parameters | |||
| 1 | Loading bucket capacity | 1.30 m3 | |
| 2 | Maximum loading and unloading height | 2650mm | |
| 3 | Excavator bucket capacity | 0.3 m3 | |
| 4 | Vehicle weight | 7800KG | |
| 5 | Engine power | 70kw | |
| 6 | Engine brand | YTO | |
| 7 | Engine model | 4108 | |
| 8 | Engine Number of cylinders | 4, Working volume 4.4L | |
| 9 | Rated engine speed | 2400r/min | |
| 10 | Engine type | four stroke water-cooled inline type | |
| 11 | Maximum excavation depth | 4800mm | |
| 12 | Maximum excavation radius | 5471mm | |
| 13 | Swivel Angle of moving arm | 85° | |
| 14 | Unloading distance of maximum height | 930mm | |
| 15 | Steering Angle | 35° | |
| 16 | Tire specification | 16/70-24 | |
| 17 | Minimum turning radius outside bucket | 4500mm | |
| 18 | Number of gear | Forward 2 gears, back 2 gears | |
| 19 | Length × width × height | 5910 * 2268 * 3760mm | |
| 20 | Maximum travel speed | 40 km / h | |
| 21 | Loader unloading height | 3.3m | |
| 22 | Battery capacity | 135AH | |
| 23 | Hydraulic system | 130L | |
| 24 | Fuel tank | 126L | |
