Electric Crane Truck 1.5 Ton 1 Ton 2 Ton Small Lithium Battery Forklift 2.5 Ton 3 Ton Forklift
- Category: >>>
- Supplier: Hitop Machinery Co. Ltd.
Share on (1600758997352):
Product Overview
Description
Products Description
Electric Crane Truck 1.5 Ton 1 Ton 2 Ton Small Lithium Battery Forklift 2.5 Ton 3 Ton Forklift
Product Details
Product Specification
Model | CPD25 | CPD30 | CPD35 | |||
Power type | Battery | Battery | Battery | |||
Rated load | KG | 2500 | 3000 | 3500 | ||
Length | With fork L1 | mm | 3380 | 3630 | 3664 | |
Without fork L2 | 2310 | 2570 | 2570 | |||
Overall height (mast lowered) H1 | 2000 | 2070 | 2070 | |||
Overall height to overhead guard H2 | 2145 | 2210 | 2210 | |||
Overall height (mast extend) H3 | 3995 | 4225 | 4225 | |||
Distance from seat to top light L3 | 1020 | 1060 | 1060 | |||
Wheel base L4 | 1515 | 1680 | 1680 | |||
Max lifting height H | 3000 | 3000 | 3000 | |||
Min Turning radius WA | 2050 | 2200 | 2500 | |||
Max lifting speed without goods | mm/s | 380 | 450 | 425 | ||
Max lifting speed with full goods | 280 | 280 | 260 | |||
Max climbing angle | % | ≤15 | ≤15 | ≤15 | ||
Whole weight | KG | 4200 | 4950 | 5600 | ||
Tyre type (Front/Rear) | Solid tyre | Solid tyre | Solid tyre | |||
Front Tyre | 7.00-12 | 28X9-15 | 28X9-15 | |||
Rear Tyre | 18x7-8 | 18x7-8 | 18x7-8 | |||
Hand Brake | Hydraulic Pedal | Hydraulic Pedal | Hydraulic Pedal | |||
Brake type | M-Hand | M-Hand | M-Hand | |||
Battery Volt/ capacity | V/Ah | 48/500 | 80/500 | 80/500 | ||
Driving motor power | Kw | 11.0AC | 16.6AC | 16.6AC | ||
Oil pump motor power | 12.0AC | 13AC | 13AC | |||
3.5ton Truck Forklift Features
High safety
1. Standard steering wheel start steering function to reduce steering operation steps.
2. A wide-view mast is standard to enhance the driving experience, and the mast and hose pulley are more compact.
3. The large arc top guard and the grid frame with better angle increase the driver's upper field of vision.
4. Optimized battery layout and counterweight design to increase rear vision.
5. The operating space under the foot increases, the accelerator pedal area increases, and the brake pedal area increases.
5. The operating space under the foot increases, the accelerator pedal area increases, and the brake pedal area increases.
Simpler maintenance
1. Equipped with a large-screen LCD display instrument, which can intuitively display the vehicle running status, with fault
display and misoperation alarm functions.
display and misoperation alarm functions.
2. Remove the rear cover of the counterweight, and you can directly inspect theelectrical control.
High reliability
1. Both driving and pump motors are maintenance-free AC motors.
2. International famous brand electric motor controller (SANTROLL, INMOTION, ZAPI, CURTIS, etc.), which is superior in intelligence.
3. Long operational life.
3. Long operational life.
Environment Friendliness
1. Zero emission, no pollution.
2. Low noise, quiet.
3. Energy efficiency, super low cost power consumption.
4. Professional matching design of vehicle components, with the use of AC controlling renewable energy technologies, the forklift is more energy saving, and working hour of the battery life is extended by about 10%~15%.
4. Professional matching design of vehicle components, with the use of AC controlling renewable energy technologies, the forklift is more energy saving, and working hour of the battery life is extended by about 10%~15%.
Optional Configurations
Multifunctional Attachments
Certifications
Company Profile
Hitop Machinery Co., Ltd. is a professional forklift manufacturer and supplier, with production base covering more than 30,000 square meters. We are an ISO9001/SGS certified enterprise. Our factory has advanced parts processing centers, hydraulic press machines, bending machines, shearing machines, welding robots, etc., as well as painting lines, final assembly lines, and performance test beds for the entire machine. We have a strict management of the quality of raw materials, parts processes, and assemblies, to ensure that our forklift trucks will have a longer life, so that the clients can get more benefits by choosing our products.
Our company has more than 15 years of experience of professional R&D technical team. We are specialized in electric forklift (battery forklift), diesel forklift, manual/electric pallet truck, manual/electric stacker, order pickers, lift table trucks, with capacity from 500kgs to 10000kgs. Most of our products are CE certified. Meanwhile, we have professional technical team in designing and producing which can meet different requirements from customers, to support OEM/ODM service, we offer 24 hours pre-sales and after-sales support, to ensure in-time communication between clients and us.
Our company has more than 15 years of experience of professional R&D technical team. We are specialized in electric forklift (battery forklift), diesel forklift, manual/electric pallet truck, manual/electric stacker, order pickers, lift table trucks, with capacity from 500kgs to 10000kgs. Most of our products are CE certified. Meanwhile, we have professional technical team in designing and producing which can meet different requirements from customers, to support OEM/ODM service, we offer 24 hours pre-sales and after-sales support, to ensure in-time communication between clients and us.
