  • Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller
Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller

Bmd400 Travel Size (Mm) 400*320 Linear Rail Wire Edm High Speed Edm Machine Wire Cut Edm Controller

Share on (1600760158632):


Price:$10,149.00 - $10,896.00

Quantity:


Product Overview

Description



Product Display




Production Specification
Machine model
BMD400
Voltage
380V/220V
Weight
2300kg
Dimension (L*W*H)
1850*1400*1800mm
Worktable size(mm)
635*415
Travel size (mm)
400*320
Max Workpiece Thichness (mm)adjustable
280mm
Max workpiece weight(kg)
400
Max Productivity(mm²/min）
≥220mm²/min
Best surface roughness(Ra)
Ra≤1.0μm
Wrie diameter(mm)
0.1-0.25mm
Taper angle
6°/80mm-12°/80mm
Accuracy(mm)
≤±0.004mm
Power supply
380V/50HZ 220V/50HZ
Power consumption
＜3KVA
