Type | Item | Description | Remark | |||
Product Style | Product Form | Surface | ||||
Dimension | 310*212*10.6mm | |||||
weight | <1kg | |||||
Material | Magnesium alloy | |||||
LCD | LCD size | 13.3" | ||||
Interface type | eDP | |||||
Resolution Support | 2560 × 1600, IPS | |||||
Touch Panel | Interface type | GFF COF GT7385, 10 Point, Full Fit, Support Capacitive Pen | MPP 2.0 | |||
Finger Print | Interface type | Support | ||||
MB Side | ||||||
USB Type_C | 1*USB3.2(USB3.0/DP/PD ,Support Thunderbolt4.0) | |||||
USB Type_C | 1*USB3.2(USB3.0/DP/PD ,Support Thunderbolt4.0) | |||||
HDMI | 1*MICRO HDMI | |||||
DB Side | ||||||
USB Type_A | 1*USB3.2 | |||||
Audio Jack | Ø3.5mm (Apple Type) | |||||
Card Reader | Micro SD card | 2-in-1 Card Holder | ||||
SIM Card | Micro SIM | |||||
RJ45 | NA | |||||
Bottom | ||||||
Pogo Pin | Support Magnetic keyboard | |||||
Key | Voice +/- | Support | ||||
Power Key | Support | Fingerprint compatible | ||||
Indicated light | Charge LED | Red Led for charging, Green Led for full charge | with MB | |||
Power LED | Blue LED | with MB | ||||
Camera LED | white light | with camera | ||||
Hardware | ||||||
CPU | Type | Intel® Core™ Tiger lake, TDP 15W | ||||
GPU | Type | Intel® UHD Graphics | ||||
Storage | RAM | LPDDR4X 200ball | ||||
ROM (eMMC) | NA | |||||
SSD | 1 *M.2 2280 (PCIE/SATA) | |||||
HDD | NA | |||||
Extended Storage | Micro SD card | |||||
Battery | Type | Li-Polymer Battery | ||||
Capacity | 7.6V 5000mAh | |||||
Fast Charge | OPTION | |||||
Camera | Front | 5MP | USB | |||
Rear | 5MP | USB;MIPI option(Through DSP to MIPI) | ||||
Sensor | G_sensor | Support | ||||
Hall Sensor | Support | |||||
Light Sensor | OPTION | |||||
Gyroscope Sensor | OPTION | |||||
Magnetometer Sensor | OPTION | |||||
Audio | Speaker | 8Ω1W*2 | ||||
Codec | 顺芯 ES8336 | |||||
MIC | 2*D-MIC in Camera Module | |||||
TPM | Interface type | Option | ||||
RTC | RTC Connector | NA | ||||
Wireless Charging | Charging power | NA | ||||
Others | NA | |||||
Network Connections | ||||||
WIFI | WIFI chip model | PCIE/CNVI colay | ||||
WIFI Standard | Support WiFi 802.11 ax/ac/a/b/g/n | |||||
WIFI Frequency | 2.4GHz/5GHz | |||||
Bluetooth | Bluetooth | support | ||||
Version | 5.0 above | |||||
LTE | 4G LTE | Support,M.2 | USB | |||
Ethernet | Gigabit LAN | NA | ||||
Modern Standby | support | |||||
Software | ||||||
OS | System | Windows 10 | ||||
Language Supported | Support Multi-language | |||||
BIOS/EC | UI spec | customization | ||||
Standard Accessories | ||||||
Magnetic keyboard | Keyboard | US Layout | ||||
Backlight | Support | |||||
Touch Pad | Support | |||||
Capacitive Pen | Type | Option, Active capacitive pen ,MPP 2.0 | ||||
Adaptor | INPUT | AC100~240V | ||||
OUTPUT | Type-C 45W | |||||
Type | Plug in wall | |||||
