Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)
Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)
Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)
Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)
Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)
Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)
Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)

Solution Crystallization Evaporator For Sewage Treatment,Zero Liquid Discharge(zld)

Share on (1600765430320):


Price:$50,000.00 - $150,000.00

Quantity:


Product Overview

Description



Product Description


Equipment overview:
MVR evaporator uses compressor to improve the energy of the secondary steam, and uses the secondary steam to improve the energy to recover the latent heat of the secondary steam. Specifically, the secondary steam generated by the evaporator is made through the adiabatic compression of the compressor to increase its pressure and temperature, and then sent into the heating chamber of the evaporator as heated steam to condense and release heat. Therefore, the latent heat of the steam is recovered and utilized. Before entering the evaporator, the cold material absorbs the heat of condensate water through the heat exchanger to increase its temperature, and also cools the condensate and the finishing liquid to further improve the utilization rate of heat.





Take concentrated industrial wastewater as an example: Firstly, the industrial wastewater enters the preheater along the pipe, and through the preheater, the industrial wastewater is preheated. The preheated industrial wastewater is then introduced into the evaporator, where it is heated, evaporated, concentrated, and finally, the distilled water from the condensation of the heated steam is transferred to the distilled water collection tank, while the secondary steam and concentrate together are transferred to the vapor-liquid separator. In the vapor-liquid separator, the concentrate and the secondary steam are separated. Finally, the concentrate flows into the concentrate collection tank, and the separated secondary steam is transferred to a mechanical compressor. In the mechanical steam compressor, the secondary steam is compressed, heated and pressurized, and introduced into the evaporator, and then the industrial wastewater is heated, concentrated, evaporated and distilled. Finally, through the repeated recycling of secondary steam, complete the entire industrial wastewater treatment process, and achieve industrial wastewater treatment and energy saving dual goals.


Specification


item
value
Condition
New
Applicable Industries
Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Food & Beverage Shops, Advertising Company, Other
Showroom Location
United States, Germany, Algeria
Video outgoing-inspection
Provided
Machinery Test Report
Provided
Marketing Type
Ordinary Product
Warranty of core components
1 Year
Core Components
Pressure vessel, Pump, Bearing, PLC
Place of Origin
China
Jiangsu
Brand Name
BLX
Material
WOODEN
Weight
18000KGS
Size
Different as each model
Power
Different as each model
Warranty
1 Year
Productivity
50000L/Hour
Weight (KG)
18000kg
Key word
Sewage Treatment System
Product name
BLX
Type
customized design
After Warranty
Video technical support


Packing & Delivery




Wood packing and container transport from shanghai port


Scope of application


1. Domestlc sewage treatment
2.Wastewater treatment for farms (plg farms, chicken farms, cattle farms, etc.)
3.Wastewater treatment for food processing plants and slaughterhouses
4.Waste water treatment for school, resort, communlty, town, buldling etc


Company Profile


Company Show
Jiangsu BaiLiXin Machinery Manufacturing CO.,LTD is located in the National Civilized City---ZhangJiagang city(nearby
Shanghai),gathered design,producing, service in integral. Our products are welcomed in Mid East,Eastern Asia, Africa and domestic
with high quality low price and top-grade services.We can provide customers for equipment installation, testing, provide related
technical formula, till the production line works. Meanwhile, maintenance can be required by customers as well. With the abundant
technical,rich experience,excellent quality and considerate after sales service,we will continue to developing, improving,and
servicing for all customers.




FAQ


1. who are we?
We are based in Jiangsu, China, start from 2014,sell to Africa(30.00%),Mid East(20.00%),South America(5.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Oceania(5.00%),Eastern Asia(5.00%),Western Europe(5.00%),Northern Europe(5.00%),Southern Europe(5.00%),South Asia(5.00%),Domestic Market(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
sewage treatment for various aspects

4. why should you buy from us not from other suppliers?
Our company is certified by the ISO9001quality management system and IOS14000 environment management system with high quality, low price and top-grade services.
We can provide equipment installation, testing, provide related technical formula,

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF；
Accepted Payment Currency:USD,CNY;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese

Any questions,please feel free to contact with us at any time.
