Motorised Monitor Stand For Conference Integration Video Conferencing Equipment Lcd Monitor Lift Mechanism
- Category: >>>
- Supplier: Guangzhou Boente Technology Co. Ltd.
Share on (1600767359510):
Product Overview
Description
BNT Motorized Retractable Monitor Lift Specification | ||||||||
Model No. | AML-17.3N | |||||||
Brand Name | BNT | |||||||
Application | Audio Video Conference System Solution | |||||||
Function | Display/ Presentation | |||||||
Build In Monitor 1 Size | 17.3" FHD screen | |||||||
Resolution | 1920*1080P | |||||||
Build In Monitor 2 Size | 10.1" FHD screen | |||||||
Monitor 2 Function | Namecard display | |||||||
Material | Aluminum Alloy Brushed | |||||||
Working Type | Automatic lifting up/down monitor | |||||||
Panel Size | 488* 78 mm | |||||||
Case Size | 473*71*600 mm | |||||||
Cut Hole Size | 475*73 mm | |||||||
Monitor 1 Tilt Angle | 0-20 degree automatic, 0-30 degree adjustable | |||||||
Interfance | VGA/H-DMI+ RS232/485 I/O+Power I/O+Network+USB | |||||||
Control Way | Switch button / RF remote / RS232/485 central control / WIFI control | |||||||
Aluminum oxidation with drawing polishing surface process to make the sure smooth and bright panel.
Build with 10.1 inch FHD screen for name display during meeting. BNT supplied software to customer to change display name information.
The tilt angle is 45 degrees, which can be adjusted to 45 degrees electrically, and can be set to 45 degrees if required.
Full metal aluminum alloy shell for mounting LED monitor screen cold rolled steel machine case for protecting the screen.
Its widely used for Video conferencing systems, TV conferencing systems, and financial analyzing systems, and so on.
Adjustable angle of the screen after lifts up.
Full metal aluminum alloy shell for mounting LED monitor screen cold rolled steel machine case for protecting the screen.
Its widely used for Video conferencing systems, TV conferencing systems, and financial analyzing systems, and so on.
Adjustable angle of the screen after lifts up.
This type of lifter uses the chain to lift, the motor has a strong lifting power, stable and durable.
Drive system: constructed by belt gearing and dual-track system that highly improves the operation stability and also makes very low noise.
Circuit Board protection system: Supply power automatically when the monitor lifts up. Power off automatically when lift down to help reduce energy consumption.
Equipped with different data interfaces for convenient data access.
Ultra-light design, all aluminum alloy (including the bottom box, including all the parts inside)
All-aluminum structure chassis, small size, super light and ultra thin design, high-quality aluminum profile and CNC carved
processing, elegant atmosphere.
Anti-pinching design, safety protection, electro-mechanical damping principle, it will bounce back when encountering any
resistance (closed door on the top panel)
All-aluminum structure chassis, small size, super light and ultra thin design, high-quality aluminum profile and CNC carved
processing, elegant atmosphere.
Anti-pinching design, safety protection, electro-mechanical damping principle, it will bounce back when encountering any
resistance (closed door on the top panel)
Product Design Drawing
15.6”, 17.3”,18.4”, 21.5” size are available, others size could be customized as request.
Equipped with different data interfaces for convenient data access.
Contact with our BNT team if would like to check other size product design drawing.
Bottom case with power input for power supply, Power output for mini PC. RS232/485 Input & output for central control system. USB-1 for USB data transfer , USB-2 for USB data transfer.
Bottom Case with VGA and H-DMI for video signal input. USB port for touch screen operation.
Could add DVI port if request.
Also have Network for name display operation
What other model BNT offer
BNT could offer other design motorized retractable Monitor lift for your choice.
Below is the popular Model for your reference.
If below model did not match your need, would like to do customized made, Kindly contact with BNT
Pop Up Monitor Lift
BNT could supply pop up monitor lift build with 13.3", 15.6", 17.3", 18.4", 21.5", 23.6" FHD screen. Non-touch screen & Touch Screen is available
Monitor +MIC Lifting Display
BNT could supply lifting display screen build with 15.6", 17.3", 18.4" and 21.5" FHD screen with lifting microphone. MIC lifting together & separate is available.
Motorized Lift for Tablet
BNT could supply motorized monitor lift for all brands tablet, like Galaxy Tablet A 10.1, Galaxy Tab A7 10.4, Ipad 12.9”Pro, Ipad 12.9” Air Pro.
We can also use this monitor lift device in schools.
Product package
BNT using anti-vibration screws lock the display to prevent shaking during transport, packed pop up monitor lift with Foam cushioning inside 5 layers of super thick kraft paper box. Packed with MDF planks into wood case for prefect protection.
We also have other motorized monitor lift products of the same series with different parameters, you can contact our customer service for a quote according to your needs.
Company Profile
Guangzhou Boente Technology Co Ltd is an integrative high-tech enterprise which collects research, development, production, sale and service for desktop socket, pop up power socket, table power socket, LCD monitor lift, TV ceiling lift and projector accessories.Over 13+ years experience in OEM and customization manufacture, 1 set larger laser cutting machine, 10 sets stamping press machine, 2 sets larger bending 10 sets larger CNC machine tools, 2 sets laser making machine, 3 lines testing machine.
→Product design team, 8 engineers with more than 10 years of CAD drawing experience, can provide design drawings within 1 hour if customized products.
→Product quality is recognized by EURO market and approval via professional 3rd Party Inspection.
→13+ years of professional design and production of lifting, after 13+ years of technical improvement and upgrading, the production technology is mature and stable, and the quality has been recognized by the foreign brand Melloni, ORNO, GLS...
→Product design team, 8 engineers with more than 10 years of CAD drawing experience, can provide design drawings within 1 hour if customized products.
→Product quality is recognized by EURO market and approval via professional 3rd Party Inspection.
